BIOS
Table 5-7
Feature
Quiet Boot
Network Stack
PXE Boot capability
Power Up In Standby
Support
Add Boot Options
ACPI Selection
USB Boot
EFI Device First
Timeout
Automatic Failover
EFI
Legacy
90
Boot Menu (continued)
Option [Default] Description
[Enabled]
Disabled
[Enabled]
Disabled
Disabled
[UEFI:IPv4]
UEFI:IPv6
UEFI:IPv4/IPv6
Legacy
[Disabled]
[First]
Last
Auto
Acpi1.0B
Acpi3.0
Acpi4.0
[Acpi5.0]
[Enabled]
Disabled
[Enabled]
Disabled
[4]
[Enabled]
Disabled
-
-
Enables or disables the booting in text mode
Enables or disables UEFI and Legacy network
support
Enables or disables the alternate PXE boot modes
-
Selects the position of an added boot device
Selects the supported ACPI version
Enables or disables USB boot support
Selects if UEFI (if enabled) or Legacy (if disabled) is
the first boot device
Selects the timeout in seconds before the first boot
attempt
Selects if another boot devices is used after the first
one failed
Change EFI boot order settings
Change Legacy boot order settings
