4.3.4

Face Plate LEDs

The following figure shows the face plate LEDs (D28 and D29).

Figure 4-6 Face Plate LEDs

Table 4-7
LED
D28
D29
PCIE-7217 Installation and Use (6806873A01B)
CPU1
Face Plate LEDs
Processor Value
Blinking Red
Solid Red
CPU1
Green
None
Blinking Blue
Blinking Red
Solid Red
CPU2
Green
None
Blinking Blue
Controls, Indicators, and Connectors
Status
On-board power failure
Processor held in reset state
CPU power UP
CPU power OFF
CPU power has been toggled
On-board power failure
Processor held in reset state
CPU power UP
CPU power OFF
CPU power has been toggled
73
