Controls, Indicators, and Connectors

4.1

Overview

This chapter contains information about the controls, indicators, and connectors associated
with the PCIE-7217 card.
4.2

Connectors

4.2.1

PCIE-7217 Face Plate View

The following figure shows the face plate view of the PCIE-7217 card.

Figure 4-1 PCIE-7217 Face Plate

Push Button Reset CPU1
Push Button Reset CPU2
USB 2.0 CPU1
USB 2.0 CPU2
Console via USB 2.0
CPU1 & CPU2
User LED CPU1
User LED CPU2
The PCIE-7217 card comes with two gold finger edge connectors referred as edge
connector 1 and edge connector 2.
PCIE-7217 Installation and Use (6806873A01B)
Chapter 4
59
