Power Requirements

The next table provides the typical power consumed by the PCIE-7217 card.
Table 2-2
Mode
Idle
Active
Peak
Idle: Both CPUs at Linux login prompt.
Active: When the CPUs are running Passmark at room temperature.
Peak: When both CPUs are at maximum operating temperature.
2.4

Precautions

To reduce the risk of personal injury, fire, or damage to the equipment, do not
overload the AC supply circuit that provides power to the chassis.
The card must be powered and connected only to a controlled voltage source.
To avoid shock, make sure that the power cables are connected to a properly wired
and grounded receptacles.
Electrostatic Discharge
Do not touch the circuit with bare hands.
The static electricity of the human body may damage the ElectroStatic Sensitive
Devices (ESSDs) on the circuit.
Make sure that you wear an ElectroStatic Discharge (ESD) preventive wrist strap or
antistatic glove to prevent the static electricity from hurting you or damaging the
device.
Keep your personal objects such as clothes and accessories away from the system.
To prevent the static electricity from damaging the device, it is recommended to
wear antistatic clothes.
PCIE-7217 Installation and Use (6806873A01B)
Power Requirements
PCIe slot power with expansion connector
30W
200W
230W
