BIOS
Caution
Incorrect settings can cause the system to malfunction. To correct mistakes, use the
<F2>
Alternatively you can press
and select Load Setup Defaults.
To select an item, use the arrow keys to move the cursor to the desired field and then use
the plus (+) and minus (-) value keys to select a value for that field. Use the Save Change
Without Exit command in the Exit menu to save the values currently displayed in all the
menus.
To display a submenu, use the arrow keys to move the cursor to the desired submenu and
then press <Enter>.
Table 5-2
Key
F1
Esc
Left and Right Arrow Keys
Up and Down Arrow Keys
F5 or F6
Enter
F9
F10
PgUp or PgDn
5.2.3

Field Help

The help text of the selected field is displayed on the right side of the screen. By scrolling
through each field, the related help text of the active selection is displayed.
80
key to return to setup and restore the system defaults by pressing
<F2>
Legend Keys
Function
Displays general help window
Exits the menu or the BIOS Setup program without saving any
changes
Selects a different menu (moves the cursor left or right)
Select an item (moves cursor up and down)
Change values
Executes command or selects a submenu
Loads the defaults configuration values for this menu
Saves the changes and exits
Moves cursor to next or previous page
to return to the BIOS setup and go to the Exit menu
PCIE-7217 Installation and Use (6806873A01B)
BIOS
<F9>
.
