disk_install.sh -d disk:<storage-device> -i bootusb -t
For example, if /dev/sda is the storage device, the command will be
disk_install.sh -d disk:sda -i bootusb -t
11. After the installation, detach the device with the installation image and then reboot.
12. Select your installation target device as boot device in the BIOS Setup Utility > Boot
menu.
6.2.1.2

Login

The following table shows the default login credentials. The shell prompt displays the name
of the PCIe card and the location of the CPU in the chassis.
For example, user@pcie7217-s1-c1 means that you are at the first CPU in slot 1.
Table 6-2
Username
root
6.2.2

Firmware Upgrade

The PCIE-7217 card has two firmware devices that need to be upgraded, when required.
The first device is the CPU with the BIOS firmware and the second is the CPLD. The root
file system includes the latest firmware images for both the devices and a firmware
command-line utility (FCU) to execute the upgrade procedure. FCU provides the following
operations:
Query the device to return the current firmware version
Show the version of a firmware image
Validate the firmware image
Verify whether the image is applicable on the target device
Upgrade the device with the given firmware image
When you call FCU with the help option fcu -–help or fcu –h, a list of supported
operations are displayed on the screen.
FCU supports specially prepared Firmware Recovery Images (FRI), which are available for
download through the SMART EC Customer Resource Center at
https://www.smartembedded.com/ec/support/.
PCIE-7217 Installation and Use (6806873A01B)
Login Credentials
Password
root
Software
97
