Cisco Remote PHY Shelf 7200 Configuration Guide for Cisco Remote PHY Shelf 7200 Software 1.1
Load for five secs: 7%/2%; one minute: 6%; five minutes: 6%
No time source, *12:41:44.228 CST Mon Mar 20 2017
LocTunID
3388764998 1054297851 0004.9f03.0214 est
Table 18: show cable rpd depi Field Descriptions
Field
LocID
RemID
US1/0/0:2(R)
est in State
P in Type

Troubleshooting Tips

Refer to the following troubleshooting tips if configuration errors occur.
If you configure DS controller profile and cable RPD, you can check the controller status, regardless of the
status of the RPD. If the channel's state is DOWN, use verbose option to view the reason.
Router#show controllers downstream-Cable 6/0/1 rf-channel 20 <verbose>
Chan State Admin Frequency Type
20

Configuration Examples

This section provides example configurations for the R-PHY Controller Profile.

Example: Controller Profile Configuration

Upstream Controller Profile Configuration
configure terminal
cable upstream controller-profile 2
cable def-phy-burst 0
us-channel 0 chan-class-id 0
us-channel 0 channel-width 1600000 1600000
us-channel 0 docsis-mode atdma
us-channel 0 equalization-coefficient
us-channel 0 frequency 50000000
us-channel 0 hop-priority frequency modulation channel-width
us-channel 0 ingress-noise-cancellation 100
us-channel 0 maintain-psd
us-channel 0 max-logical-chans 1
RemTunID Remote Device
Description
Local session ID.
Remote session ID.
US means UEPI session, DS means DEPI session. This string means UEPI session on line
card slot 1, controller 0, rf-channel 2.
Established state.
On primary line card.
UP UP 231000000 VIDEO-SYNC B
Cisco Remote PHY Shelf 7200 Software Configuration Guide for Cisco Remote PHY Shelf 7200 Software 1.1
State Remote Address Sessn L2TP Class
Count
10.10.10.11 29
Annex Mod srate Interleaver dcid output
256 5361 I128-J1
Troubleshooting Tips
rphy-l2tp-gl...
- NORMAL
65
