Verifying Time Interface and PTP Domain Configuration
Parameter
announce timeout [value]
unicast grant-duration
[value]
description
Verifying Time Interface and PTP Domain Configuration
The following example shows how to verify the time interface and PTP domain configuration:
Router# show ptp clock running domain 55
Name
slave-from-903 unicast
slave-from-903 [Lo1588] [Sessions 1]
Peer addr
10.10.1.11
Configure RPD PTP Connection
To configure RPD PTP connection, use the following commands.
enable
configure terminal
interface type [slot_#/]port_#
ptp r-dti 55(RPD PTP connection)
profile G.8275.2
ptp-domain 0
clock-port <same domain number with PTP server>
clock source ip <IP Address> gateway ip <IP Address>
clock source ip <IP Address> gateway ip <IP Address> alternate
!--<clock-source is PTP master loopback ip, gw is the next hop to reach the ptp master>--!
Verifying RPD PTP Connection Configuration
The following example shows how to verify the RPD PTP Connection configuration:
Router# show ptp clock 0 config
Domain/Mode
Priority 1/2/local
Profile
Total Ports/Streams : 1
--PTP Port 188, Enet Port
Cisco Remote PHY Shelf 7200 Software Configuration Guide for Cisco Remote PHY Shelf 7200 Software 1.1
18
Cisco Remote PHY Shelf 7200 Start Up Configuration Guide for Cisco Remote PHY Shelf 7200 Software 1.1
Description
Set timeout interval for
announcement packets
Set the grant duration time
in seconds for unicast
Clock port name or
description
PTP Ordinary Clock [Domain 55]
State
Ports
PHASE_ALIGNED
1
PORT SUMMARY
Tx Mode
Role
slave
SESSION INFORMATION
Pkts in
Pkts out
45126
16012
:
0/OC_MASTER
: 128/255/128
: 001b19000100-000000 E2E
/0
0 ----
Value Range
3-255
60-1000
Pkts sent
Pkts rcvd
16012
45126
Transport
State
Lo1588
Uncalibrated 1
In Errs
Out Errs
0
0
Default Value
300
Redundancy Mode
Hot standby
PTP Master
Sessions
Port Addr
10.10.1.11
