To display the RPD get IPv6 address by Stateful method, use the show dhcp command.
R-PHY#show dhcp
Interface
vbh0
Details:
--------------------------------------------------------------------------------
Interface:
AddrType:
TimeServers:
TimeOffset:
LogServers:
CCAPCores:

Configuring PTP

To configure PTP, use the following example as reference:
On cBR-8 router:
interface Loopback1588
ip address 159.159.159.4 255.255.255.255
interface TenGigabitEthernet5/1/3
ip address 192.104.10.4 255.255.255.0
ip route 10.90.3.93 255.255.255.255 192.104.10.93
ptp clock ordinary domain 0
servo tracking-type R-DTI
clock-port slave-from-903 slave
ptp r-dti 1
ptp-domain 0
clock-port 1
1=vbh0, ethernet 2=vbh1 */
gateway is ASR903 BDI ID for node */
On ASR903 router as PTP master:
ptp clock ordinary domain 0
IP-Address
2001:93:3:58::d8
delay-req interval -4
sync interval -5
sync one-step
transport ipv4 unicast interface Lo1588 negotiation
clock source 10.90.3.93
/* same domain number with ptp server */
ethernet 1 /* default value is same index with clock-port index, for RPD, ethernet
clock-source 10.90.3.93 gateway 93.3.10.2
Cisco Remote PHY Shelf 7200 Software Configuration Guide for Cisco Remote PHY Shelf 7200 Software 1.1
Subnet-Mask
ffff:ffff:ffff:ffff::
vbh0
IPv6<Stateful>
2001:20:1:1::33
28800
2001:20:1:1::33
2001:93:3:58::1
/* connect to ASR903 */
/* route to ASR903 loopback ip */
/* ASR903 loopback ip */
/* clock-source is ASR093 loopback ip,
