5�5�1� Updating Firmware With Rdu101 Card Connection - Vertiv Liebert GXT5 Series Installer/User Manual

The latest firmware is available for download from the GXT5 product page at
below, and make sure you have the correct files for the update�
UPS MODEL NUMBER
GXT5-500LVRT2UXL
GXT5-750LVRT2UXL
GXT5-1000LVRT2UXL
GXT5-1500LVRT2UXL
GXT5-2000LVRT2UXL
GXT5-3000LVRT2UXL
For DSP update files:
• "P"" represents the power module� The number following "P" is the version of the power module�
• "D" represents the rectifier and inverter module� The number following "D" is the version of the rectifier and inverter module�
• "K" is included after the version for the DSP kernel upgrade file, for example: GXT5_Micro_0�5k-3k_P***K�bin)
For MCU update files:
"M" represents the MCU module� The number following "M" represents the MCU software version�
5.5.1. Updating Firmware with RDU101 Card Connection
If your UPS has an IntelliSlot RDU101 communication card installed (optional on some models), you can update
firmware with a computer connected to the same network as the card�
NOTE: The RDU101 card is password protected. Be sure to obtain the user name and password from an
administrator. The name and password may have been changed from the default.
NOTE: For detailed operating instructions for the card, refer to the Liebert® IntelliSlot™ RDU101
Communications Card Installer/User Guide, available at www.Vertiv.com.
Updating MCU Firmware via RDU101
NOTE: Do not update firmware while the UPS is on Battery mode.
1� Connect a network cable to the RJ-45 Ethernet port of the RDU101 card� For the card/connection location, refer
to the appropriate rear-panel description for your UPS model in
2� On a computer connected to the same network as the RDU101, open a browser window and enter the IP address
of the RDU101 card in the address bar�
You can get the card's IP address from the display panel� Select the About menu then the Product tab,and locate
IPv4 address�
NOTE: We recommend using the Google Chrome browser.
3� Upload the update file using the card's user interface, see
a� Select the "GXT5" tab, then the File Transfer folder in the tab-menu pane on the left-hand side of the page�
b� On the file-transfer page, click Choose File, and select the MCU upgrade file, then click Transfer file�
Vertiv | Liebert® GXT5™ | Installer/User Guide
Table 5-2 Upgrade File Names by UPS Model
DSP FIRMWARE FILENAME
GXT5_Micro_0�5k-3k_P***�bin
www� V ertiv�com� Refer to
MCU FIRMWARE FILENAME
GXT5_M***�bin
Rear Panels on page
Figure 5-2 on the next page�
Table 5-2
5�
55
