Liebert®
GXT5™ UPS
230 V Input, 230 V Output
I
Installer/User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liebert GXT5-750IRT2UXL and is the answer not in the manual?

Questions and answers

Summary of Contents for Vertiv Liebert GXT5-750IRT2UXL

  • Page 1 Liebert® GXT5™ UPS 230 V Input, 230 V Output Installer/User Guide...
  • Page 2 Vertiv. This document is the property of Vertiv and contains confidential and proprietary information owned by Vertiv. Any copying, use or disclosure of it without the written permission of Vertiv is strictly prohibited. Names of companies and products are trademarks or registered trademarks of the respective companies.
  • Page 3: Table Of Contents

    Chapter 2: Installation �����������������������������������������������������������������������������������������������������������������������������������������������������������������������21 2� 1 � Unpacking and Inspection ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 21 2�2� Pre-installation Preparation ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 21 2�2�1� Installation Clearances ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 21 2�3� Installing the UPS ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 2�3�1� Tower Installation �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 2�3�2� Rack Installation �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������22 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 4 3�2� Starting-up the UPS ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 43 3�3� Transferring to Battery Mode �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������44 3�4� Transferring from Normal to Bypass Mode ������������������������������������������������������������������������������������������������������������������������������������������������44 3�5� Transferring from Bypass to Normal Mode �������������������������������������������������������������������������������������������������������������������������������������������������44 3�6� Shutting-down the UPS Completely ��������������������������������������������������������������������������������������������������������������������������������������������������������������������45 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 5 5�4� Cleaning the UPS ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ 76 5�5� Replacing the Power-distribution Box ���������������������������������������������������������������������������������������������������������������������������������������������������������������77 5�6� Firmware Updates ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 79 5�6�1� Updating Firmware with RDU101 Card Connection ��������������������������������������������������������������������������������������������������������������� 79 5�7� Updating DSP Firmware via RDU101 ������������������������������������������������������������������������������������������������������������������������������������������������������������������ 82 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 6 6�2� Audible Alarm (Buzzer) �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������87 6�2�1� Faults �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������88 6�3� Troubleshooting UPS Issues �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������88 Chapter 7: Specifications ��������������������������������������������������������������������������������������������������������������������������������������������������������������89 7�1� Battery Run Times ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������100 Appendix I: Open Source Software Legal Notices ���������������������������������������������������������������������������������������� 107 Appendix II: Technical Support ������������������������������������������������������������������������������������������������������������������������������������������ 109 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 7: Important Safety Information

    IMPORTANT! This manual contains important safety instructions that must be followed during the installation and maintenance of the UPS and batteries. Read this manual thoroughly and the safety and regulatory information, available at https://www.vertiv.com/ComplianceRegulatoryInfo, before attempting to install, connect to supply, or operate this UPS.
  • Page 8 This page is intentionally left blank� Important Safety Information...
  • Page 9: Chapter 1: Gxt5 Description

    MODEL NUMBER NOMINAL POWER RATING @ 230 V INPUT GXT5-750IRT2UXL 750 VA/750 W GXT5-750IRT2UXLE GXT5-1000IRT2UXL 1000 VA/1000 W GXT5-1000IRT2UXLE GXT5-1500IRT2UXL 1500 VA/1500 W GXT5-1500IRT2UXLE GXT5-2000IRT2UXL 2000 VA/2000 W GXT5-2000IRT2UXLE GXT5-3000IRT2UXL 3000 VA/3000 W GXT5-3000IRT2UXLE Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 10: 1�2� Front Panels

    Table 1-1 UPS Models and Power Ratings MODEL NUMBER NOMINAL POWER RATING @ 230 V INPUT GXT5-5000IRT5UXLN 5 kVA/5 kW GXT5-5000IRT5UXLE GXT5-6000IRT5UXLN 6 kVA/6 kW GXT5-6000IRT5UXLE GXT5-8000IRT5UXLN 8 kVA/8 kW GXT5-8000IRT5UXLE GXT5-10KIRT5UXLN 10 kVA/10 kW GXT5-10KIRT5UXLE GXT5-16KIRT9UXLN 16 kVA/16 kW GXT5-16KIRT9UXLE GXT5-20KIRT9UXLN 20 kVA/20 kW...
  • Page 11: 1�3� Rear Panels

    Programmable C13 output receptacles C14 input-power plug and cable Terminal-block communication connectors RS-232 port - RJ-45/RJ-11 connection used for command line interface RS-485 port - RJ-45 connection used for external temperature sensors USB port Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 12 Figure 1-3 GXT5-1500IRT2UXL (XLE) Rear Panel ITEM DESCRIPTION Liebert® IntelliSlot™ port Ventilation Hole External-battery-cabinet connector Input circuit-breaker reset button, 10-A Non-programmable C13 output receptacles Programmable C13 output receptacles C14 input-power plug and cable Terminal- block/Dry-contact communication connectors RS-232 port - RJ-45/RJ-11 connection used for command line interface RS-485 port - RJ-45 connection used for external temperature sensors USB port GXT5 Description...
  • Page 13 C20 input-power plug and cable Input circuit-breaker reset button, 16-A Terminal-block/Dry-contact communication connectors RS-232 port - RJ-45/RJ-11 connection used for command line interface RS-485 port - RJ-45 connection used for external temperature sensors USB port Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 14 Figure 1-5 GXT5-3000IRT2UXL (XLE) Rear Panel ITEM DESCRIPTION Liebert® IntelliSlot™ port Ventilation Hole External-battery-cabinet connector Non-programmable C19 output receptacle Output circuit-breaker reset buttons, 10-A Non-programmable C13 output receptacles Programmable C13 output receptacles C20 Input-power plug and cable Input circuit-breaker reset button, 20-A Terminal-block/Dry-contact communication connectors RS-232 port - RJ-45/RJ-11 connection used for command line interface RS-485 port - RJ-45 connection used for external temperature sensors...
  • Page 15 Programmable output circuit breaker, 10-A (x2) Output circuit breaker - Controls terminal block output and non-programmable output receptacles Maintenance bypass breaker Removable junction box with cable entry for hard-wire I/O Input circuit breaker Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 16 Figure 1-7 GXT5-8000/10KIRT5UXLN (XLE) Rear Panel ITEM DESCRIPTION Liebert® IntelliSlot™ port Terminal- block communication connectors USB port RS-485 port - RJ-45 connection used for external temperature sensors RS-232 port - RJ-45/RJ-11 connection used for command line interface REPO connector DB9 ports - Used for communication when operating in a parallel system, see 2�8�...
  • Page 17 DB9 ports - Used for communication when operating in a parallel system, see 2�8� Installing a Parallel System Input circuit breaker Bypass circuit breaker Knock-outs/cable-entry for hard-wire I/O Output circuit breaker POD breaker Cover for optional POD-installation location External-battery-cabinet connector Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 18: 1�4� Removable Power Distribution Box

    1.4. Removable Power Distribution Box The 16-kVA and 20-kVA do not ship with an installed power-distribution box (POD)� The optional PODs for the 16-kVA and 20-kVA models are: • PD2-108 for models ending in "N" only (North America) • PD2-200 •...
  • Page 19: 1�5� Internal Battery Packs

    UPS� 3-kVA and below units have 1 battery pack, 5-kVA and 10-kVA units have 2 battery packs, and 16-kVA to 20-kVA units have 4 battery packs� The battery pack size varies based on: Figure 1-11 Internal Battery Pack ITEM. DESCRIPTION Handle Connector Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 20: 1�6� Battery Cabinet

    1.6. Battery Cabinet Optional battery cabinets are available for the UPS, and include a single battery-connector cable� Up to 10 battery cabinets may be connected in parallel to the UPS, and up to 6 can be detected using EBC - detection� See Table page 98 Table 7-9...
  • Page 21: 1�7�1� Maintenance Bypass

    UPS� Maintenance bypass keeps connected equipment powered with utility power and allows replacement of the UPS in the event of a UPS malfunction� NOTE: The bypass power path does not protect the connected equipment from disturbances in the utility power supply. Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 22: 1�8� Ups States And Operating Modes

    1.8. UPS States and Operating Modes NOTE: See LED Indicators page 49, for description of the run-indicator and alarm-indicator LEDs mentioned in this section. 1.8.1. Normal Mode When utility power is normal, Normal mode employs the rectifier and inverter to provide voltage- and frequency- stabilized power to the load�...
  • Page 23: 1�8�2� Bypass Mode

    UPS shuts down and no output is supplied to the load. Figure 1-15 Bypass-mode Operation ITEM DESCRIPTION Mains/Utility input (by-pass input) Rectifier/PFC Inverter Battery charger Battery Bypass static switch UPS output Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 24: 1�8�3� Battery Mode

    1.8.3. Battery Mode Battery mode supplies battery power to the load if utility power fails or if the utility voltage goes outside of the permissible range� On the front-panel display, the run indicator (green) is ON, the alarm indicator (yellow) is ON, and the buzzer beeps once each second�...
  • Page 25: 1�8�4� Eco Mode

    NOTE: The UPS has no user-serviceable parts. If the UPS malfunctions and requires service, visit http://www. Vertiv.com/en-us/support/ or contact your local Vertiv representative. Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 26 Figure 1-17 Maintenance Bypass-mode Operation ITEM DESCRIPTION Mains/Utility input (by-pass input) Rectifier/PFC Inverter Battery charger Battery Bypass static switch UPS output Maintenance by-pass GXT5 Description...
  • Page 27: Chapter 2: Installation

    • Inspect the UPS for shipping damage� If any shipping damage is found, report it to the carrier and your local Vertiv representative immediately� • Check the accessories included against the packing list� If there is any discrepancy, contact your local Vertiv representative immediately�...
  • Page 28: 2�3� Installing The Ups

    2.3. Installing the UPS The UPS may be installed as a tower or in a rack, depending on available space and use considerations� Determine the type of installation and follow the appropriate instructions� See Tower Installation Rack Installation below� NOTE: When installing the UPS or making input and output connections, comply with all relevant safety codes and standards.
  • Page 29: 2�4� Installing External Battery Cabinets

    To install the EBC(s): 1� Inspect the EBC for freight damage� Report damage to the carrier and your local dealer or Vertiv representative� 2� For tower installation: • An additional set of support-base extensions ships with each EBC�...
  • Page 30 Figure 2-2 EBCs connected to the 5/6 K UPS ITEM DESCRIPTION EBC-detection dry-contact port (See Table 2-3 page 30, for details�) EBC connector EBC-detection port External battery cabinet External battery cabinet Installation...
  • Page 31 Figure 2-3 EBCs connected to the 8/10 K UPS ITEM DESCRIPTION EBC-detection dry-contact port (See Table 2-3 page 30, for details�) EBC connector EBC-detection port External battery cabinet External battery cabinet Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 32: 2�5� Installing A Power Distribution Box

    2.5. Installing a Power distribution Box WARNING! Risk of electric shock Can cause equipment damage, injury and death. Before beginning installation, verify that all external overcurrent protection devices are open (Off), and that they are locked-out and tagged appropriately to prevent activation during the installation, verify with a voltmeter that power is Off and wear appropriate, OSHA-approved personal protective equipment (PPE) per NFPA 70E.
  • Page 33: 2�6� Hardwired Input/Output Connections

    Table 2-1 I/O Connection Types by Model MODEL LINES IN/OUT CONFIGURATION 5-kVA, 6-kVA 1-in 1-out Common source 8-kVA, 10-kVA 1-in 1-out Common Source or Split bypass 16-kVA, 20-kVA 1-in 1-out or 3-in 1-out Common Source or Split bypass Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 34: 2�6�1� Branch Circuit Breaker

    2.6.1. Branch Circuit Breaker The installer must provide an upstream branch circuit breaker, see Table 2-2 below, for the ratings� The input circuit breaker on the distribution box and the output circuit breaker on the rear of the power distribution box disconnect all power between the main cabinet and the distribution box�...
  • Page 35 Figure 2-5 Circuit-breakers diagram ITEM DESCRIPTION Mains/Utility External branch Circuit Breaker Input Maintenance Bypass Circuit Breaker Output Input Circuit Breaker Output Circuit Breaker UPS-PFC, battery inverter Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 36: 2�6�2� Terminal-Block Connections

    2.6.2. Terminal-block Connections On 5-kVA and 10-kVA models, the hard-wire connections to the terminal blocks are made through knockouts on the POD attached to the rear of the unit� See Removable Power Distribution Box page 12, for the location of the input/output knockouts on your GXT5 model� Models below 3000 VA use input cords with plugs instead of terminal block connections�...
  • Page 37 30, when making the connections� Figure 2-7 below, shows the shorting cable installed for a split-bypass connection� Figure 2-7 Terminal Block 8 kVA to 10 kVA Models ITEM DESCRIPTION Output Bypass Input Shorting cable (installed at factory) Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 38: 2�6�5� Connecting To Terminal Blocks On 16-Kva And 20-Kva Models

    2.6.5. Connecting to Terminal Blocks on 16-kVA and 20-kVA models These models offer a four types of I/O connection� One shorting cable (W01) ships installed on the terminal block� Two additional shorting cables are included with the accessories to wire the different types Figure 2-8 below, shows the terminal block�...
  • Page 39: 2�7� Communication Connections

    2� Insert the card into the slot, and secure with the screws that held the cover plate� To make connections to the card, refer to the Installer/User Guide for the appropriate IntelliSlot card available at www�vertiv�com� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 40: 2�7�2� Connecting To The Dry-Contact Port

    2.7.2. Connecting to the Dry-contact Port The UPS includes a dry-contact port� See the appropriate figure for your model in Rear Panels page 5, for the location of the port� Figure 2-11 below, shows the ports and Table 2-4 describes each port� The I/O dry contact port ratings are 125 Vac, 0�5 A;...
  • Page 41 NC, Pins 11 and 12 are opened when the fault occurs� Output 6 11, 12 Remote Fault Alert 6 Options are: • Low battery • On battery • On bypass • UPS fault (default) Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 42: 2�7�3� Connecting A Remote Emergency Power-Off (Repo) Switch

    2.7.3. Connecting a Remote Emergency Power-off (REPO) Switch The UPS includes an EPO connection in the dry-contact port� See the appropriate figure for your model in Rear Panels page 5, for the location of the port� UPS ships with a REPO jumper installed, allowing the UPS to operate as a normally-closed switch system (fail-safe)� Opening the circuit disables the UPS�...
  • Page 43: 2�7�4� Connecting A Usb Cable

    Power Assist from www�vertiv�com� 2.7.5. Connecting CLI Communication Cables The UPS supports the Vertiv command-line interface for operation with Vertiv ACS and other third-party monitoring protocols� The RJ-45 port (labeled “R232”) is used for CLI connection� See the appropriate figure for...
  • Page 44 NOTE: 8-kVA and lower models do not support paralleling at this time. NOTE: You must use Vertiv parallel cables for the connection. NOTE: If a fault occurs during parallel-system operation, shut-off the system and make sure the cables are...
  • Page 45: 2�8�1� First-Time Start-Up Of A Parallel System

    2� Wait about 30 seconds to allow the rectifier start-up to finish, then at each UPS, set the parallel parameters as follows: NOTE: If the “Parallel Comm Fail” Alarm displays, clear it and proceed. Communication should not fail after the parallel settings are synchronized. Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 46: 2�8�2� Commissioning Parallel System

    • On the display, press Enter to display the Main Menu, then use the arrow buttons to select Settings, and press Enter� NOTE: To adjust the settings, you must enter a password. See Editing Display and Operation Settings page 69, for details on entering the password and editing the setting parameters. •...
  • Page 47: 2�8�3� Adding A Single Ups To The Parallel System

    4� On the added UPS, close the input and output breakers, wait about 30 seconds to allow the rectifier start-up to finish, then power-on the inverter� 5� Make sure that there are no alarms and that the UPS and the parallel system are operating normally� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 48 This page is intentionally left blank� Installation...
  • Page 49: Chapter 3: Operating The Ups

    8� If this is the first-time start-up of the UPS, the Start-up Guidance wizard opens to set the basic parameters of the UPS� Follow the prompts� For detailed description of UPS display functions and settings, see Operation and Display Panel page 47� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 50: 3�3� Transferring To Battery Mode

    3.3. Transferring to Battery Mode The UPS operates in Normal mode unless the mains/utility power fails or it is performing a battery self test, then it automatically transfers to Battery mode for the back-up time available or the mains/utility power is restored� Once input power is restored, the UPS returns to Normal mode�...
  • Page 51: 3�6� Shutting-Down The Ups Completely

    To manually power-off in an emergency, disconnect the terminal connecting the REPO port on the rear of the UPS� If mains/utility power is present, the UPS control circuit remains active even though output power is disabled� To remove all mains/utility power, disconnect the external main-input circuit breaker� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 52 This page is intentionally left blank�...
  • Page 53: Chapter 4: Operation And Display Panel

    Run indicator LED, see LED Indicators page 49� Alarm indicator LED, see LED Indicators page 49� Power button, see Table 4-1 on the next page� Menu keys, see Table 4-1 on the next page� LCD panel� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 54 Table 4-1 Display-panel Button Functions and Descriptions BUTTON FUNCTION DESCRIPTION Enter Confirm or enter selection� Move to previous page, increase value, move left� Down Move to next page, decrease value, move right� Escape Go back� Power Power-on the UPS, power-off the UPS, transfer to Bypass Mode� NOTE: While the UPS is operating, the LCD will dim and display a screen saver if there is no active alarm or user interaction for two minutes, see Figure...
  • Page 55: 4�1� Led Indicators

    Use the function keys to navigate through the menu, and view statuses or select settings in the screens� 4.2.1. Start-up and Flow Screens At start-up, the UPS executes a system test and displays the Vertiv logo screen for about 10 seconds, shown Figure 4-1 page 47�...
  • Page 56: 4�2�2� Main Menu

    64� About Product and network information, see About Screen page 66� Maintenance Service-only, service-password protected page for use only by Vertiv service representatives� Figure 4-4 Main Menu ITEM DESCRIPTION ECO-mode indicator Ambient Temperature Date and Time Operation and Display Panel...
  • Page 57: 4�2�3� Status Screen

    Input Status Options L-N voltage (V) Line-neutral voltage of input power� L-N current (A) Line-neutral current of input power� Frequency (Hz) Frequency of input of input power� L-L voltage(V) Line-line voltage of input power� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 58 Power Factor Power factor of the input power� Energy (kWh) Input power� Input black count The number times that the input voltage was lost or dropped below 60 VAC (black out)� Resets to 0 when UPS is powered down� Input brown count The number of times that the input voltage was too low to support the load and the UPS was forced to switch to battery power (brown out)�...
  • Page 59 Line-neutral current of output power� Frequency (Hz) Frequency of output power� L-L voltage(V) Line-line voltage of output power� Energy (kWh) Output power� Load Status Options Sout (kVA) Apparent output power� Pout (kW) Active output power� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 60: 4�2�4� Settings Submenu

    Power Factor Power factor of output power� Load percent (%) Percentage of recent power rated to output power� 4.2.4. Settings Submenu The settings screen consists of tabs that list UPS settings for configuration and adjusting parameters with tabs for: • Output •...
  • Page 61 • Normal = Connected load is always powered through the UPS inverter� ECO mode is disabled� • ECO mode = ECO mode is enabled� The UPS inverter is bypassed, and the connected load is powered by utility/mains power within the selected ECO voltage and frequency tolerances� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 62 Sets the number of attached external battery cabinets or allows the number of EBCs to be detected automatically with Autodetect� Autodetect is used only for Vertiv EBCs� If more than 6 Vertiv EBCs are connected, autodetect does not function and this must be set manually� For third-party external batteries, set this option to 0 and use “External battery AH”...
  • Page 63 • Disable (default) Replace battery Activates newly-installed battery packs after replacement and reset all battery statistics for new battery packs� • Provides a confirmation window with Yes/No options to confirm replacement of batteries� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 64 Monitor Settings Options Language Selects the language of the display, see Selecting the Display Language page 70� • English (default) • French • Portuguese • Spanish • Chinese • German • Japanese • Russian Date Selects the current date for the UPS display, YYYY-MM-DD� See Setting the Date and Time page 71�...
  • Page 65 Automatically restart the UPS after an “Any mode shutdown” signal is received� When the UPS is shut down via dry-contact inputs 1 or 2, it will restart automatically if this option is enabled� • Enable • Disable (default) Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 66 Output contact NO/NC Selects the states of the dry contact outputs 5 and 6� • Normally open (default) • Normally closed Input contact NO/NC Selects the states of the dry contact inputs 1 and 2� • Normally open (default) • Normally closed Dry contact 5 (Output) Selects the output of dry-contact 5�...
  • Page 67 Outlet1 and apply identical settings to any other programmable outlet� Turn on/off outlet Turns on or turns off the outlet based on the current state� Provides a confirmation window with Yes/No options to confirm turning on the outlet� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 68 Turn on delay Length of time before outlet turns on after UPS start-up� • 0 to 30 minutes (default is 0) Turn off when UPS overloads Sets whether or not to turn off the outlet if the UPS is overloaded while on battery power� This can be used to disable lower priority equipment in the event of an overload while in battery mode�...
  • Page 69: 4�2�5� Control Screen

    Clears displayed faults after the issue causing the fault is resolved, see Table 6-2 page 88 , for a description of the faults� Reset power statistics Resets the values tracked to calculate the Efficiency graph, see About Screen page 66� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 70: 4�2�6� Log Screen

    Table 4-4 Alarm Messages MESSAGE DESCRIPTION Aux� power fault UPS internal auxiliary power voltage fault� Contact Vertiv Technical Support� Battery cabinet More than 10 external battery cabinets are connected to the UPS� Disconnect excess battery cabinets� connect abnormal The battery has reached the end of discharge and mains/utility power is unavailable� Restore the mains power� The UPS will Battery EOD power off if it is not restored�...
  • Page 71 The inverter is off due to DC bus voltage out of acceptable range� The load will transfer to bypass if the bypass is available DC bus abnormal because the bus voltage is outside of the acceptable range� The discharger is faulty, because the bus voltage exceeds the range when the discharger starts� Contact Vertiv Technical DC/DC fault Support�...
  • Page 72: 4�2�7� About Screen

    A short has occurred on the output� Check the output cables and for any equipment that may have shorted� The rectifier is off because the bus voltage is out of the acceptable range when the rectifier starts� Contact Vertiv Technical Rectifier fault Support�...
  • Page 73 Shows the IPv4 address of the RDU101 card� This is only shown when the RDU101 card is installed� Subnet mask Shows the subnet mask of the RDU101 card� This is only shown when the RDU101 card is installed� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 74 Gateway address Shows the gateway address of the RDU101 card� This is only shown when the RDU101 card is installed� Efficiency Tab Capacity This shows the maximum capacity of your UPS model� Cap. (%) This shows the percentage of the maximum capacity your UPS is currently using� Eff.
  • Page 75: 4�3� Editing Display And Operation Settings

    ‘Turn on/Turn off/to Bypass’ on the LCD panel ‘Control’ page)� Cannot set this on line, please Appears when attempting to change the output phase number while the output is connected� unplug REPO Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 76: 4�3�2� Changing The Password

    4.3.2. Changing the Password The default password is 111111 (six ones)� You must use the current password to change the password� NOTE: We recommend that you change the password from the default to protect your system and equipment. Record the new password and store it in an accessible location for later retrieval. 1�...
  • Page 77: 4�3�4� Setting The Date And Time

    5� Use the up/down arrows to select the date/time, then press Enter to confirm� 6� Use the down arrow to select the digit to change and the up arrow to select the correct digit� Repeat as needed to set each digit� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 78 This page is intentionally left blank�...
  • Page 79: Chapter 5: Maintenance

    • Do not lay tools or metal parts on top of batteries� • Disconnect input power prior to connecting or disconnecting battery terminals� • If the battery kit is damaged in any way or shows signs of leakage, contact your Vertiv representative immediately�...
  • Page 80 (such as a rack or server closet)� To obtain the appropriate replacement battery pack(s), refer to Table 5-1 below and contact your local dealer or Vertiv representative� Table 5-1 Replacement Battery-pack Model Numbers UPS MODEL NUMBER...
  • Page 81 5� Compare the new and old battery pack to make sure they are the same type and model� If so, proceed with step 6� If they are different, stop and contact your Vertiv representative, or Technical Support, http://www� V ertiv�com/ en-us/support/�...
  • Page 82: 5�2� Charging Batteries

    4� Check the flow screen to ensure the UPS is operating in Normal mode� If the UPS is operating in Bypass mode, contact Vertiv Technical Support� 5� Check the flow screen to see if batteries are discharging (operating in Battery mode) while utility power is normal� If so, contact Vertiv Technical Support� 5.4. Cleaning the UPS WARNING! Risk of electric shock Can cause injury or death.
  • Page 83: 5�5� Replacing The Power-Distribution Box

    8� On the rear of the panel, loosen the screws of the protective cover for the connectors, slide it over the connectors, and tighten the screws� NOTE: The captive screws and maintenance-bypass breaker cover is similar for all 5- to 10-kVA models. Figure 5-2 on next page shows an example on the 5-kVA model. Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 84 Figure 5-2 Maintenance-bypass Breaker Cover and Captive Screws ITEM DESCRIPTION Captive screws for POD Maintenance-bypass breaker Connector-cover screws Maintenance...
  • Page 85: 5�6� Firmware Updates

    Both may be updated through a connection the UPS, using CLI and the R232 port or, if the UPS includes the IntelliSlot RDU101 card, using the RJ-45 port on the card� The latest firmware is available for download from the GXT5 product page at www�vertiv�com� Refer to Table 5-2 below, and make sure you have the correct files for the update�...
  • Page 86 Updating MCU Firmware via RDU101 NOTE: Do not update firmware while the UPS is on Battery mode. 1� Connect a network cable to the RJ-45 Ethernet port of the RDU101 card� For the card/connection location, refer to the appropriate rear-panel description for your UPS model in Rear Panels page 5�...
  • Page 87 Figure 5-3 File Transfer on the RDU101 User Interface ITEM DESCRIPTION "UPS" tab, typically the UPS model number File Transfer folder Choose File button Transfer File button Status of file transfer Figure 5-4 Firmware Version on the RDU101 User Interface Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 88: 5�7� Updating Dsp Firmware Via Rdu101

    5.7. Updating DSP Firmware via RDU101 NOTE: Only update the DSP firmware while the UPS is in Stand-by mode. The REPO terminal of the UPS must be un-plugged. When the REPO terminal is unplugged the load will lose power. Do not update firmware while the UPS is on Battery mode.
  • Page 89 You can check the firmware version, select the System folder in the tab-menu pane on the left-hand side of the page, and check the Firmware Version field, see Figure 5-7� Figure 5-6 File Transfer on the RDU101 User Interface Figure 5-7 Firmware Version on the RDU101 User Interface Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 90: 5�8� Updating Firmware With A Cli Connection

    5.8. Updating Firmware with a CLI Connection You can use the Vertiv command-line interface to update firmware with a computer connected to the R232 (RJ- 45) port on the rear of the UPS� To perform the update via CLI, you need the following: •...
  • Page 91 2� Connect the RJ-45 connector to the R232 port on UPS� For the connection location, refer to the appropriate rear-panel description for your UPS model in Rear Panels page 5� 3� Connect the DB9 connector to a computer with the serial-terminal emulator installed� Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 92 4� Open the serial-terminal emulator, and adjust the settings to communicate with the UPS: • Select “Serial” connection for the session� • Check the computer “device management” settings for the communication port (for example COM6),and select the same port in the emulator� •...
  • Page 93: Chapter 6: Troubleshooting

    NOTE: When an alarm is indicated, an alarm message is logged. Table 4-4 page 64, describes the alarm messages you may see. When a fault is indicated, front-panel display list the fault, which are described in Table below. Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 94: 6�2�1� Faults

    Vertiv Technical Support� Visit the GXT5 product page at www�vertiv�com for contact information� When reporting a UPS issue to Vertiv, include the UPS model and serial number� These are located in several places for your ease of location: • On the top panel (rack mount orientation) •...
  • Page 95: Chapter 7: Specifications

    Up to 10,000 ft� (3000 m) at 77 ºF (25 ºC) without derating Audible Noise <46 dBA max @ 3 ft� (1 m) front and sides <43 dBA max @ 3 ft� (1 m) rear Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 96 Table 7-1 UPS Specifications, 750 VA and 1000 VA models (continued) MODEL GXT5- 750IRT2UXL 750IRT2UXLE 1000IRT2UXL 1000IRT2UXLE RATING 750 VA/750 W 1000 VA/1000 W Agency EN 62040-1:2008+A1:2013; Safety GS mark; UL 1778 5th Edition and CSA 22�2 No� 107�1 EN 62040-2:2006 EN 61000-3-2:2014 EN 61000-3-3:2013 Transportation...
  • Page 97 161 ~ 288 VAC 28% ~ 70% loading 115 ~ 288 VAC 0 ~ 28% loading 115 ~ 288 VAC Frequency 40Hz ~ 70Hz; Auto Sensing Input Power Cord Output AC Output Receptacles C13×6&C19 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 98 Table 7-3 UPS Specifications, 3000 VA Models (continued) MODEL GXT5- 3000IRT2UXL 3000IRT2UXLE RATING 3000 VA/3000 W Voltage 200/208/220/230/240 VAC (user-configurable); ±3% Waveform Sine wave >200% for 250 ms Utility(AC) Model 150- 200% for 2 seconds Overload 125- 150% for 50 seconds 105-125% 60 seconds Internal Charger Charging current...
  • Page 99 0 – 95% non-condensing Operating Elevation Up to 3,000 m (9,842�5 ft) at 25°C (77°F) without derating Audible Noise <55 dBA, at 1 meter from the front, <50 dBA, at 1 meter from rear or sides Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 100 Table 7-4 UPS Specifications, 5-kVA and 6-kVA models (Continued) MODEL: GXT5- 5000IRT5UXLN 5000IRT5UXLE 6000IRT5UXLN 6000IRT5UXLE 5000 VA/5000 W 6000 VA/6000 W RATING Agency Parameters Safety IEC62040-1:2008 version, GS mark EMI/EMC/C-Tick EMC IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 6) IEC/EN EN61000-4-2, Level 4, Criteria A Radiated Susceptibility IEC/EN EN61000-4-3, Level 3, Criteria A...
  • Page 101 IEC/EN EN61000-4-2, Level 4, Criteria A Radiated Susceptibility IEC/EN EN61000-4-3, Level 3, Criteria A Electrical Fast IEC/EN EN61000-4-4, Level 4, Criteria A Transient Surge Immunity IEC/EN EN61000-4-5, Level 4, Criteria A Transportation ISTA Procedure 1E Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 102 Table 7-6 UPS Specifications, 16-kVA and 20-kVA models MODEL: GXT5- 16KIRT9UXLN 16KIRT9UXLE 20KIRT9UXLN 20KIRT9UXLE RATING 16000 VA/16000 W 20000 VA/20000 W Dimensions, mm (in.) Unit, WxDxH 430×630×394 (16�9×24�8×15�5) Shipping, WxDxH 900×1200×700 (35�4×47�2×27�6) Weight, kg (lb) Unit 135�2 (298) Shipping 190 (418�9) 186�7 (411�6) 190 (418�9) 186�7 (411�6)
  • Page 103 Two IEC320 C19 16 A/250 V Sockets Four IEC320 C19 16 A/250 V Sockets Includes Six C13 10 A/250 V Sockets Four C13 10 A/250 V Sockets Input Branch Circuit 50 A 63 A Breaker, Supplied by User Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 104 Table 7-8 External Battery Cabinet Specifications, 750 VA to 3000 VA models MODEL NUMBER GXT5-EBC36VRT2U GXT5-EBC48VRT2U GXT5-EBC72VRT2U USED W/UPS MODEL 750 – 1,000 VA MODELS 1,500 – 2,000 VA MODELS 3,000 VA MODELS Dimensions, D×W×H, in. (mm) 14�6 x 16�9 x 3�3 19�7 x 16�9 x 3�3 23�7 x 16�9 x 3�3 Unit...
  • Page 105 -15 to 40 (5 to 104) Relative Humidity 0 – 95% non-condensing Operating Elevation Up to 3,000 m (9,842�5 ft�) at 25°C (77°F) Agency Parameters Safety IEC62040-1:2008 version, GS mark; UL1778, c-UL listed Transportation ISTA Procedure 1E Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 106: 7�1� Battery Run Times

    7.1. Battery Run Times NOTE: Run times in this table are approximate. Times are based on new, fully-charged, standard battery modules at a temperature of 77 °F (25 °C) with 100% resistive UPS loading. Run times listed above can vary by ±5% due to manufacturing variances of the individual batteries.
  • Page 107 103�9 129�3 154�3 179�9 204�6 230�7 257�6 1800 1800 4�0 22�0 42�9 66�5 88�9 113�0 136�0 158�2 180�4 202�5 225�2 2000 2000 3�2 18�8 38�1 57�1 79�8 99�9 119�3 140�7 161�0 180�6 200�6 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 108 Table 7-14 Battery Run Time, 3000 VA Models NUMBER OF EXTERNAL BATTERY CABINETS INTERNAL LOAD BATTERY ONLY Minutes 78�9 260�2 457�8 654�1 866�5 1084�9 1296�1 1488�8 1641�8 1762�7 1860�5 36�7 136�3 233�3 337�8 447�1 556�0 660�9 775�9 892�7 1011�1 1131�0 21�9 88�4 157�2...
  • Page 109 48�0 59�5 71�5 83�0 95�0 106�5 118�5 7200 7200 4�0 11�5 20�5 30�5 41�0 52�0 62�5 73�0 83�5 94�0 104�5 8000 8000 3�5 9�5 17�5 26�5 36�0 45�5 55�5 64�5 74�0 83�5 93�0 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 110 Table 7-18 Battery Run Time, 10-kVA Models NUMBER OF EXTERNAL BATTERY CABINETS INTERNAL LOAD BATTERY ONLY Minutes 1000 1000 59�0 129�0 211�0 294�0 377�0 460�0 543�0 625�5 708�5 791�5 874�5 2000 2000 25�0 62�5 99�0 136�0 179�5 222�5 266�0 309�5 353�0 396�5 439�5...
  • Page 111 36�5 46�5 56�5 66�0 75�5 85�0 94�5 18000 18000 3�0 8�5 15�0 23�0 31�0 40�0 48�5 57�5 66�0 74�5 83�0 20000 20000 2�5 7�0 13�0 19�5 27�0 34�5 42�5 50�5 58�0 66�0 73�5 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 112 This page is intentionally left blank� Specifications...
  • Page 113: Appendix I: Open Source Software Legal Notices

    Appendix I: Open Source Software Legal Notices The GXT5 product links the FreeRTOS software with Vertiv Group Corporation’s proprietary modules that communicate with the FreeRTOS software solely through the FreeRTOS API interface� This use is an exception to the FOSS GPLv2 license� The user is free to redistribute the FreeRTOS software and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation�...
  • Page 114 This page is intentionally left blank� Open Source Software Legal Notices...
  • Page 115: Appendix Ii:technical Support

    Toll +39 02 98250222 In the United States Technical support e: liebert�upstech@vertiv�com p: 1-800-222-5877 menu option 1 Monitoring support e: liebert�monitoring@vertiv�com p: 1-800-222-5877 menu option 2 Warranty support e: microups�warranty@vertiv�com p: 1-800-222-5877 menu option 3 Vertiv | Liebert® GXT5™ | Installer/User Guide...
  • Page 116 This page is intentionally left blank� Technical Support...
  • Page 117 © 2019 Vertiv Group Corp. All rights reserved. Vertiv™ and the Vertiv logo are trademarks or registered marks of Vertiv Group Corp. All other names and logos referred to are trade names, trademarks, or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein.
