TROUBLESHOOTING

®
TABLE 4: SIMPLICITY
Light
PWR This is the power light and should show steady green at all times when the Simplicity Linc is powered.
The SYS ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady red light will
SYS ERROR
indicate there is a system error on the Simplicity Linc. If this occurs, contact UP Tech Services at 1-877-874-7378
COMM COMM ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady red light will
ERROR indicate the communications problem if there is a configured node connected to the Simplicity Linc that is offline.
Config ERR LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. A steady amber light will
Config
indicate a configuration error exists in the active configuration. If this occurs, contact UP Tech Services at 1-877-
ERROR
874-7378
Node Offline LED will go on solid 15 seconds after power up. It will turn off after 5 seconds. If the Node Offline LED
Node Offline
stays on solid, a node offline condition has occurred.
Unused 15 seconds after powering up the 4 unused LEDs will turn on solid for 5 seconds, then turn off.
RX On normal operation of Simplicity Linc, the RX LED will flash when a message is received on the field port.
TX On normal operation of Simplicity Linc, the TX LED will flash when a message is sent on the field port.
RUN LED will flash 20 seconds after power up, signifying normal operation. During the first 20 seconds, the LED
RUN
should be off.
Power Source
Frequency
Power Consumption
Operating Environment
Size (H x W x D)
Weight
Type
SDRAM Memory
FLASH Memory
Port 1 Type
Port 1 Speeds
Port 1 Connector
Port 2 Type
Port 2 Speeds
Port 2 Connector
LAN Cable
LEDs
Switch Selections
Johnson Controls Unitary Products
LINC GATEWAY LED TROUBLESHOOTING
Description
General
24 ± 15% VAC (Obtained from the Roof Top Unit)
45 to 65 HZ
Nominal >2 VA
-40 to 160° F (-40 to 70° C) 10 to 95% non-condensing
5.0 x 2.4 x 1.8 in. (128 x 61 x 45.75 cm)
0.2 lb. (0.09 kg)
Processor
Microchip
2048 bytes
1024 bytes w/1,000,000 write cycle capability
Interface
BACnet MS/TP
9.6, 19.2, 38.4, 76.8 kbaud
3-pin screw terminals
Modbus RTU (RS485)
9.6, 19,2 kbaud
6-pin screw terminals
Screened Twisted-Pair (Belden 9272 or 89272)
Controller Status; BACnet; Modbus
MAC Address (1-99), Baud Rate
