TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
BACnet BACnet
Read/
Object Object
Write
Type Inst
R (5) BI 81
R (5) BI 74
R (5) BI 77
R / W (5) BV 28
R / W (5) BV 13
R / W (2) AV 89
R / W (2) AV 88
R / W (5) BV 19
R (5) BI 14
R / W (2) AV 28
R / W (2) AV 30
R / W (5) BV 110
R / W (2) AV 85
R (5) BI 11
R / W (5) BV 9
R / W (2) AV 61
R / W (5) BV 6
R (2) AI 16
R (2) AI 48
R / W (2) AV 1
R / W (2) AV 50
R / W (5) BV 1
R / W (5) BV 93
R (2) AI 17
R (2) AI 49
Johnson Controls Unitary Products
Descriptor
I_LIMIT_1
I_LPS1
I_LPS2
INTELLI-STRT
LOADSHED
LOW_AMB_ECON_MIN
LOW_AMB_ECON_STPT
LOW_AMB_OVRD
LOW_SUP_VOLT
MAX_TH_OFSET
MAX_DMV_ECON
MIN_AMB_SEN
MIN_AMB_TEMP_SP
MODBUS_ALARM
MOD_EX_INST
MWU_RAT_STPT
MORN_WARM-UP
NUMBER_COMPS
NUMBER_HEAT
OCC_COOL_SP
OCC_HEAT_SP
OCCUPIED_ENA
OCC_COMS_ENA
OP_COOL_STPT
OP_HEAT_STPT
Default Min Max Point Description
Intelli-Comfort Limit Switch #1 Input
n/a n/a n/a
Status
Intelli-Comfort Low Pressure Switch for
n/a n/a n/a
Compressor #1 Input Status (1=closed,
0=open / fault)
Intelli-Comfort Low Pressure Switch for
n/a n/a n/a
Compressor #2 Input Status (1=closed,
0=open / fault)
n/a n/a n/a
Intelli-Start Enabled
Loadshed (0=clear loadshed, 1=set
n/a n/a n/a
loadshed operation)
Low Ambient Economizer Minimum
0 0 99
Position (Percent) (0 disables)
Low Ambient Economizer Temperature
0 0 60
Setpoint (0 disables)
Low Ambient Temperature (0=comps
n/a n/a n/a
not overridden by LAT, 1=comps
overridden)
Low Supply Voltage (0=comps not
n/a n/a n/a
overridden by LSV, 1=comps
overridden)
Max Temperature / Humidity Setpoint
3 0 5
Offset
Maximum Demand Ventillation
50 0 100
Economizer Position
n/a n/a n/a
Minimum Outdoor Air Sensor Enabled
Minimum Outdoor Air Temperature
0 0 100%
Setpoint (0-100%)
n/a n/a n/a
Modbus Communication Alarm
n/a n/a n/a
Modulating Exhaust Installed
Morning Warm-Up and VAV Heating:
70 50 85
Return Air Temperature Setpoint
(degrees F)
n/a n/a n/a
Morning Warm-Up Enabled
2 4
Number of Compressors Available
Number of Heat Stages Available (0,0, 0
n/a n/a n/a
stage, 0,1= 1 stage, 1,0= 2 stage, 1,1= 3
stage)
72 46 99
Occupied Cooling Setpoint
68 45 98
Occupied Heating Setpoint
n/a n/a n/a
Occupied Input Enabled
Occupied Thermostat or
n/a n/a n/a
Communication Input Enabled
n/a n/a n/a
Operating Cooling Setpoint
68 45 99
Operating Heating Setpoint
