CONNECTION

®
The Simplicity LINC has 2 ports, one for connection to the BAS
network (BACnet) and one to the Simplicity

BACNET NETWORK

The only connection required in the field is to the BACnet (BAS)
network.
NOTE: Proper termination and grounding of the shields must
be observed.
DIP switches A0-A7 on the Simplicity
selection of the MAC Address. The MAC Address identifies the
®
Simplicity LINC to other devices and must be between 1 and
99. The default DIP switch setting is 1.
A Device Instance (DE) Modifier is used by the Simplicity
and defaulted to 230. The combination of the DE Modifier and
the default DIP switch setting creates a default DE of 23001.
The default Unit Name is YORK_RTU.
MAC Address of 21
A0 1
A1 2
A2 4
A3 8
A4 16
A5 32
A6 64
A7 128
MAC Address of 99
A0 1
A1 2
A2 4
A3 8
A4 16
A5 32
A6 64
A7 128
FIGURE 2: MAC ADDRESS EXAMPLES
2
®
board (Modbus).
®
LINC board allow
®
LINC
1
0
4
0
16
0
0
0
21
1
2
0
0
0
32
64
0
99
DIP switches B0-B3 on the Simplicity
selection of the BACnet transfer speed.The default speed is set
at 38.4k baud. Other speeds can be chosen as shown in Table
1
.
TABLE 1: BAUD RATE SELECTION SETTINGS
DIP Setting
1
2
3
4
5
6
7
8
9
10
11(Default)
12
13
14
Baud Rate of 38400
B0 1
B1 2
B2 4
B3 8
®
LINC board allow for
Baud Rate
110
300
600
1200
2400
4800
9600
19200
20833
28800
38400
57600
76800
115200
1
2
0
8
11
