TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
BACnet
BACnet
Read/
Object
Object
Write
Type
R / W
(5) BV
R / W
(5) BV
R / W
(5) BV
R / W
(5) BV
R / W
(5) BV
R / W
(5) BV
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
R
(5) BI
Johnson Controls Unitary Products
Descriptor
Inst
34
CVM_COOLING
35
CVM_HEATING
36
ECO_L_TO_SAT
37
OAH_SENSOR
38
RAH_SENSOR
39
DEMAND_VENT
40
E_IFAN_STAT
41
E_FAN_ OVER
42
E_COMP1_STAT
43
E_LPS1
44
E_HPS1
45
E_C1_OVRLOAD
46
E_COMP2_STAT
47
E_LPS2
48
E_HPS2
49
E_C2_OVRLOAD
50
E_CFAN1_STAT
51
E_COMP3_STAT
52
E_LPS3
Default
Min
Max
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
1031990-UAD-A-0313
Point Description
Comfort Ventilation Mode for Cooling
Enabled
Comfort Ventilation Mode for Heating
Enabled
Economizer Loading to Control Supply
Air Temperature Enabled
Outside Air Humidity Sensor Enabled
Return/Inside Air Humidity Sensor
Enabled
Demand Ventilation (using Inside
Sensor) Enabled
Elite Indoor Fan Output Status
(0=output is OFF, 1=output is ON)
Elite Fan Overload Switch Input Status
(1=closed, 0=open / fault)
Elite Compressor #1 Output Status
(0=output is OFF, 1=output is ON)
Elite Low Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
Elite High Pressure Switch for
Compressor #1 Input Status (1=closed,
0=open / fault)
Elite Compressor #1 Overload Switch
Input Status (1=closed, 0=open / fault)
Elite Compressor #2 Output Status
(0=output is OFF, 1=output is ON)
Elite Low Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
Elite High Pressure Switch for
Compressor #2 Input Status (1=closed,
0=open / fault)
Elite Compressor #2 Overload Switch
Input Status (1=closed, 0=open / fault)
Elite Condenser Fan #1 Output Status
(0=output is OFF, 1=output is ON)
Elite Compressor #3 Output Status
(0=output is OFF, 1=output is ON)
Elite Low Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
17
