Johnson Controls Simplicity LINC Application Manual page 7

TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
BACnet BACnet
Read/
Object Object
Write
Type Inst
R (5) BI 47
R (5) BI 52
R (5) BI 56
R (2) AI 32
R (5) BI 30
R / W (5) BV 10
R / W (2) AV 91
R / W (2) AV 92
R / W (2) AV 93
R / W (2) AV 94
R / W (2) AV 90
R (5) BI 102
R (5) BI 32
R (5) BI 104
R (5) BI 105
R (5) BI 106
R (5) BI 107
R (5) BI 68
R (5) BI 69
R (5) BI 70
R (2) AI 76
R (2) AI 77
R (2) AI 78
R / W (5) BV 25
R / W (2) AV 27
R (5) BI 18
Johnson Controls Unitary Products
Descriptor
E_LPS2
E_LPS3
E_LPS4
EXH_DAMP_OUT
EX_FAN_STAT
EX_VFD_INST
FAN_SPD_1ST_COOL
FAN_SPD_1ST_HEAT
FAN_SPD_ALL_COOL
FAN_SPD_ALL_HEAT
FAN_SPD_NO_HEAT_COOL
4_STG_EXP_PRES
FRECOOL_STAT
FREEZE_STAT_1
FREEZE_STAT_2
FREEZE_STAT_3
FREEZE_STAT_4
HEAT_1_STAT
HEAT_2_STAT
HEAT_3_STAT
H1_ACCUM_HRS
H2_ACCUM_HRS
H3_ACCUM_HRS
HEATING_ENA
HGR_HUM_STPT
HGR_STAT
Default Min Max Point Description
Elite Low Pressure Switch for
n/a n/a n/a
Compressor #2 Input Status (1=closed,
0=open / fault)
Elite Low Pressure Switch for
n/a n/a n/a
Compressor #3 Input Status (1=closed,
0=open / fault)
Elite Low Pressure Switch for
n/a n/a n/a
Compressor #4 Input Status (1=closed,
0=open / fault)
Exhaust Damper Output Status (0-
n/a n/a n/a
100%)
Exhaust Fan Output Status (0=output is
n/a n/a n/a
OFF, 1=output is ON)
n/a n/a n/a
Exhaust VFD Installed
70 0 100
Fan Speed: 1st Stage Cooling
100 0 100
Fan Speed: 1st Stage Heating
100 0 100
Fan Speed: All Stages Cooling
100 0 100
Fan Speed: All Stages Heating
50 0 100
Fan Speed: No Heating No Cooling
n/a n/a n/a
Four Stage Expansion board Present
Free Cooling Mode Status (0=comps
n/a n/a n/a
not overridden by Econo, 1=comps
overridden)
n/a n/a n/a
Freeze Stat # 1
n/a n/a n/a
Freeze Stat # 2
n/a n/a n/a
Freeze Stat # 3
n/a n/a n/a
Freeze Stat # 4
H1 Heating Output #1 Status (0=output
n/a n/a n/a
is OFF, 1=output is ON)
H2 Heating Output #2 Status (0=output
n/a n/a n/a
is OFF, 1=output is ON)
H3 Heating Output #3 Status (0=output
n/a n/a n/a
is OFF, 1=output is ON)
Heating #1 Accumulated Run Time (in
n/a n/a n/a
hours)
Heating #2 Accumulated Run Time (in
n/a n/a n/a
hours)
Heating #3 Accumulated Run Time (in
n/a n/a n/a
hours)
n/a n/a n/a
Heating Mode Enabled
Hot Gas Reheat Humidity Setpoint
50 0 100
(percent Humidity)
Hot Gas Reheat Output Status
n/a n/a n/a
(0=output is OFF, 1=output is ON)
1031990-UAD-A-0313
7
