Johnson Controls MAP Series Installation Instructions Manual

Mobile Access Portal Gateway Installation Instructions
Applications
The Mobile Access Portal (MAP) Gateway is an alternate
local display solution or a temporary portable
commissioning device that enables users to leverage the
power of mobility using smart phones, tablets, or laptop
computers to interact with building automation equipment
controls. The MAP Gateway serves up web pages through
a built-in Wi-Fi access point or tethered Ethernet
connection, which allows users to view and edit
equipment controller configuration parameters, setpoints,
schedules, and alarms through a browser. A mobile
application is not required to use the MAP Gateway with
your mobile device.
The MAP Gateway can be used to see field bus devices
on Metasys® systems, Facility Explorer systems, and
Smart Equipment rooftop units (RTUs) with unit control
boards (UCBs). The MAP Gateway supports
Johnson Controls® branded Field Controllers, including
FEC, FAC, VMA, PCA, PCG, and PCV Series devices.
MAP Gateway also supports the TEC3000 Series
Thermostats.
The wireless connection on the MAP Gateway allows
users of a supported mobile device to be up to 30 m (100
ft, line of sight) away indoors and up to 91 m (300 ft, line
of sight) away outdoors. Power may be supplied via the
SAB (sensor/actuator bus), the FCB (field controller bus),
a supplied external power supply, or a micro USB port.
The MAP Gateway comes in two configurations: a
portable configuration and a stationary configuration.
Configuration is chosen at purchase, and the accessories
shipped with the MAP Gateway depend on the
configuration chosen.
When used as a portable device, the MAP Gateway can
be attached to a lanyard. In this configuration, the MAP
Gateway can be carried from site to site, depending on
the needs and workflow of field personnel.
When used as a stationary device, the MAP Gateway
can be permanently mounted directly to a wall or DIN rail
using the supplied MAP Gateway mounting cradle.
Mobile Access Portal Gateway Installation Instructions
Refer to the QuickLIT website
North American Emissions
Compliance
United States
This equipment has been tested and found to comply
with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when this equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area may cause harmful interference, in which
case the users will be required to correct the interference
at their own expense.
RF Transmitters: Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
RF Exposure (OET Bulletin 65)
To comply with FCC RF exposure requirements for
mobile transmitting devices, this transmitter should only
be used or installed at locations where there is at least
20 cm separation distance between the antenna and all
persons.
Part No. 24-10737-8, Rev. F
Software Release 4.0
Issued April 2016
for the most up-to-date version of this document.
1
