Johnson Controls Simplicity LINC Application Manual page 18

1031990-UAD-A-0313
TABLE 3: POINTS LIST IN OBJECT ORDER (CONTINUED)
BACnet BACnet
Read/
Object Object
Write
Type
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R (5) BI
R / W (5) BV
R (5) BI
R (5) BI
R (5) BI
18
Descriptor
Inst
53 E_HPS3
54 E_C3_OVRLOAD
55 E_ COMP4_STAT
56 E_LPS4
57 E_HPS4
58 E_C4_OVRLOAD
59 E_CFAN2_STAT
60 E_GAS_VLVE1
61 E_LIMIT_ 1
62 E_GAS_VLVE2
63 E_LIMIT_ 2
64 E_GAS_VLVE3
65 E_LIMIT_ 3
66 E_FREEZE_ST
67 FAN_HEAT
68 HEAT_1_STAT
69 HEAT_2_STAT
70 HEAT_3_STAT
Default Min Max
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
n/a n/a n/a
Point Description
Elite High Pressure Switch for
Compressor #3 Input Status (1=closed,
0=open / fault)
Elite Compressor #3 Overload Switch
Input Status (1=closed, 0=open / fault)
Elite Compressor #4 Output Status
(0=output is OFF, 1=output is ON)
Elite Low Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
Elite High Pressure Switch for
Compressor #4 Input Status (1=closed,
0=open / fault)
Elite Compressor #4 Overload Switch
Input Status (1=closed, 0=open / fault)
Elite Condenser Fan #2 Output Status
Input Status (0=output is OFF,
1=output is ON)
Elite Gas Valve #1 Input Status
(1=energized, 0=not energized)
Elite Limit Switch #1 Input Status
(1=closed, 0=open / fault)
Elite Gas Valve #2 Input Status
(1=energized, 0=not energized)
Elite Limit Switch #2 Input Status
(1=closed, 0=open / fault)
Elite Gas Valve #3 Input Status
(1=energized, 0=not energized)
Elite Limit Switch #3 Input Status
(1=closed, 0=open / fault)
Hot H2O Freeze Thermostat Switch
Input Status (1=closed, 0=open / fault)
Turn OFF Continuous Fan when
Starting Heat Enabled (0=Continuous
Fan ON)
H1 Heating Output #1 Status (0=output
is OFF, 1=output is ON)
H2 Heating Output #2 Status (0=output
is OFF, 1=output is ON)
H3 Heating Output #3 Status (0=output
is OFF, 1=output is ON)
