  • Page 1 CEG and TMR Technical Bulletin Building Technologies & Solutions LIT-12013900 www.johnsoncontrols.com 2023-01-31 Johnson Controls...
  • Page 2 © 2023 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice. Johnson Controls...
  • Page 3: Table Of Contents

    TMR address on the MS/TP network....................... 21 Baud rate determination...........................21 Required setup for cloud operation......................21 Editing the equipment description for the Connected Equipment Portal........21 Configuring the SC-Equip connected services port MAC address..........22 Configuring the remote services connection...................22 CEG and TMR Technical Bulletin Johnson Controls...
  • Page 4 Wireless network topologies......................37 Self-healing, multi-hop network......................37 TMR system mesh network technology implementation...............38 Physical layer channels........................38 Appendix D: CEG security..........................38 Product warranty............................38 Software terms............................... 38 Patents................................38 Single point of contact...........................39 Contact information............................39 CEG and TMR Technical Bulletin Johnson Controls...
  • Page 5: Introduction

    The CEG uses BACnet MS/TP open protocol to monitor chiller operation. The gateway can communicate either through hardwired RS-485 or wirelessly, using mesh network technology with self-healing capabilities. The CEG then aggregates, packages, and transmits the data to the Johnson CEG and TMR Technical Bulletin Johnson Controls...
  • Page 6 CEP web UI. The CEG follows the same guidance for MS/TP rules as other Johnson Controls devices, including a limitation of number of devices on a Field Controller (FC) bus when third-party devices are present.
  • Page 7 Figure 2: TMR and CEG wireless connected system overview Figure 3: TMR and CEG mixed connection system overview Note: The TMR wireless mesh network is independent of any building IT systems and does not require any preexisting wireless infrastructure. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 8: Ceg And Tmr System Components

    • The TMR connects directly to the MS/TP bus of the controller with the controller running in MS/TP mode. • The TMR can support any Johnson Controls or third-party BACnet MS/TP controller. The ZFR18xx radios only work with select Johnson Controls field controllers.
  • Page 9: Connected Equipment Gateway

    The CEG is a supervisory device that monitors BACnet MS/TP equipment and sends data to cloud- based services. The CEG supports Johnson Controls and third-party chillers. When you use the CEG with a TMR, you can connect the wireless enabled BACnet MS/TP controllers over the TMR wireless mesh network.
  • Page 10: Performance Considerations For Third-Party Bacnet Devices

    AREA and Personal Area Network (PAN) OFFSET to be unique between the two networks. Installing the TMR About this task: Refer to the TMR Installation Guide (Part No. 24-11461-00020) for the full details about how to install the TMR. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 11: Ceg Wired Network Installation

    CEG version 2.0 or earlier. The Tempered Airwall zero-trust software uses Host Identity Protocol to secure network communication between the CEG and the cloud. In addition, it secures communication for any remote access requirements. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 12: Using The Airwall Bypass

    BAS bus and requires the use of the Airwall 110E gateway device. • Connect the RJ-12 cable between the SC-EQ CS RJ port J1 and the CEG FC Bus 6-pin RJ-12 connector as shown in the following figure. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 13: Connecting Wired Bacnet Ms/Tp Network Equipment

    You must set the following BACnet MS/TP parameters when you join the CEG to an existing network. You can adjust all the parameters listed in the following table in the CEG UI in the Settings > BACnet Settings menu. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 14: Tmr Wireless Network Characteristics

    An increased number of hops that a message takes through the mesh can result in a higher probability of errors and decrease reliability of the wireless network. Note: The default and maximum Tx power setting depends on the model and regional regulatory agencies. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 15: Wireless Network Device Limits

    • Loss of critical control would result from loss of data from humidity or temperature sensor communications. • Operation of exhaust fans or air handling units (AHUs) would impair a purge or pressurization mode. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 16: Area And Pan Offset Setting For A Wireless Network

    TMR and CEG. If you use the terminal block, the SA PWR can be 15 to 24 VAC/ VDC. For the details, refer to the TMR and CEG installation documentation. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 17: Connecting Multiple Tmr Coordinators To A Ceg

    The standard CEG Panel provides space to install a second TMR coordinator. You can also mount an additional TMR coordinator external to the CEG Panel, if the equipment is located in separate areas where it is not recommended to extend the mesh, for example, floors, wings, buildings. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 18: Connecting The Tmr Wireless Router To A Bacnet Device

    You can connect multiple MS/TP controllers to the same TMR router. This is useful if you install the controllers in the same control panel, or in close proximity, so that it is more economical to hard wire the controllers together, rather than to connect a separate TMR to each controller. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 19: Installing The Tmr As A Wireless Repeater

    LED blinks at 1 Hz. If the PAN is closed for joining, the TMR LED is on steady blue with a green blink to indicate that it is attempting to join the selected PAN. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 20: Adding New Wireless Devices To A Running Network

    During this time, the WEFC may display a Not Supported indication. Navigate to the Diagnostics page on the CEG local UI to check the performance of the wireless mesh network, including online status and wireless signal strength. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 21: Tmr Bacnet Ms/Tp Operation

    In the Description field, enter the description sent to you from the CEP onboarding team. Note: Even if the CEP did not provide a description, you must enter a unique description for all monitored and non-monitored devices. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 22: Configuring The Sc-Equip Connected Services Port Mac Address

    • Replacing an existing TMR wireless coordinator, router, or repeater • Advanced operations: - Upgrading firmware - Changing the active wireless channel - Changing the transmit power - Disabling the token proxy feature Replacing an existing TMR coordinator About this task: CEG and TMR Technical Bulletin Johnson Controls...
  • Page 23: Adding Or Replacing A Tmr Router Or Repeater

    Install the new TMR router or repeater and wire it to the chiller or power source. The new TMR joins the network and its signal strength LED blinks in red. Wait for up to 5 minutes for the CEG to recognize that the TMR is added or replaced. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 24: Advanced Operations

    Token proxy The TMRs use a priority scheme to pass the token for other MS/TP devices detected on remote MS/TP segments. This scheme makes it possible for some Johnson Controls devices, for example CEG and TMR Technical Bulletin Johnson Controls...
  • Page 25: Troubleshooting

    The following section provides a general troubleshooting information for the CEG and the TMR Series Wireless Field Bus. CEG LED status The CEG uses status LEDs to indicate functional states according to the LED map shown in the following table: CEG and TMR Technical Bulletin Johnson Controls...
  • Page 26 The Wi-Fi dongle is not detected or the Wi-Fi client CLIENT interface is turned off. Flashes The router is not authenticated. On solid The router is authenticated. CLOUD Not currently supported. CELLULAR n/a Not currently supported. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 27: Tmr Led Status

    In this case, eliminate each possible cause. Note: One or more warnings can be active at one time. Use the following table as a guide on what to check. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 28 • If you replaced a defective using the same AREA and PAN setting. coordinator with a new one, do a factory reset on all the existing TMR routers and reopen the network so that they can join. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 29: Using The Tmr Join Button

    TMR joins, and its LED blinks in red according to the signal strength. Note: If you do not press the join button a second time, the LED stops blinking after five seconds and the TMR returns to normal operation. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 30: General Wireless Network Stability

    • Confirm that the TMR routers are wired correctly to the MS/TP bus of the field equipment. • Confirm that the network is open for new devices to join. • Ensure that the address switch 128 is set to off for Johnson Controls FEC, FAC, IOM, or VMA. The LED of a TMR The CEG has not yet commanded the TMR into coordinator mode.
  • Page 31: Troubleshooting Issues With The Tmr Routers And The Wefcs

    The TMR is set as coordinator. To recover the TMR as a router perform a connected to the MS/ factory reset. The normal operating state color for the TMR is green. TP device is yellow. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 32: Cellular Signal Strength

    TMR returns to normal operation. TP device is aqua. Cellular signal strength You can view the signal strength through the LEDs on the cell modem or through a connection with your PC. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 33: Viewing The Signal Strength Through Led

    If your PC or laptop is configured to automatically retrieve an IP address, it can obtain the IP address from the device. Otherwise, ensure your PC or laptop can connect to network 192.168.1.0 (255.255.255.0). CEG and TMR Technical Bulletin Johnson Controls...
  • Page 34: Appendix A: Tmr Wireless Security

    Wireless spectrum basics • The Johnson Controls wireless solution is based on the 802.15.4 standard operating at 2.4 GHz frequency. • The 2.4 GHz spectrum is unlicensed and shared with Wi-Fi, streaming video, and Bluetooth.
  • Page 35 • Some sites may exhibit interference after the initial installation. Not all Wi-Fi is managed within the building, for example, channels are rotated or varied so that the same channel does not exist directly above or below a specific PAN. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 36: Appendix C: Tmr Wireless Mesh Network Overview

    This technique expands the typically short range of an individual node into a much larger, widespread network consisting of multiple nodes. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 37: Network Device Types

    Within the mesh network, a single message is allowed to hop 30 times between the source and destination node. CEG and TMR Technical Bulletin Johnson Controls...
  • Page 38: Tmr System Mesh Network Technology Implementation

    Your use of this product constitutes an agreement to such terms. Patents Patents: https://jcipat.com CEG and TMR Technical Bulletin Johnson Controls...
