TABLE 2: POINTS LIST IN DESCRIPTION ORDER (CONTINUED)
BACnet BACnet
Read/
Object Object
Write
Type Inst
R (2) AI 47
R (5) BI 66
R (2) AI 55
R / W (5) BV 2
R / W (5) BV 3
R / W (2) AV 62
R / W (2) AV 63
R / W (2) AV 80
R (2) AI 45
R (5) BI 73
R (2) AI 46
R (5) BI 76
R (5) BI 79
R (5) BI 72
R (5) BI 82
R (5) BI 83
R (5) BI 80
R (5) BI 75
R (5) BI 78
R (5) BI 71
8
Descriptor
HGR_VLV_OUT
E_FREEZE_ST
HW_VLV_OUT
HYDRONC_HEAT
HH_REVER_VLV
HYD_S1_SA_SP
HYD_S2_SA_SP
IO_DVNT_STPT
I_C1_ACM_HRS
I_COMP1_STAT
I_C2_ACM_HRS
I_COMP2_STAT
I_CFAN_STAT
I_FAN_OVER
I_FREEZE_1
I_FREEZE_2
I_GAS_VLVE1
I_HPS1
I_HPS2
I_IFAN_STAT
Default Min Max Point Description
Hot Gas Reheat Valve Output Status (0-
n/a n/a n/a
100%)
Hot H2O Freeze Thermostat Switch
n/a n/a n/a
Input Status (1=closed, 0=open / fault)
Hot Water Valve Output Status (0-
n/a n/a n/a
100%)
n/a n/a n/a
Hydronic Heat Enabled
Hydronic Heat Reverse Actuated Valve
n/a n/a n/a
Installed
Hydronic Heating Stage #1 Supply Air
120 80 180
Setpoint (degrees F)
Hydronic Heating Stage #2 Supply Air
150 81 180
Setpoint (degrees F)
Indoor / Outdoor Demand Ventilation
700 0 2000
Setpoint
Intelli-Comfort Compressor #1
n/a n/a n/a
Accumulated Run Time (in hours)
Intelli-Comfort Compressor #1 Input
n/a n/a n/a
Status (0=output is OFF, 1=output is
ON)
Intelli-Comfort Compressor #2
n/a n/a n/a
Accumulated Run Time (in hours)
Intelli-Comfort Compressor #2 Input
n/a n/a n/a
Status (0=output is OFF, 1=output is
ON)
Intelli-Comfort Condenser Fan #1 Input
n/a n/a n/a
Status (0=output is OFF, 1=output is
ON)
Intelli-Comfort Fan Overload Switch
n/a n/a n/a
Input Status (0=open,1=closed)
Intelli-Comfort Freeze Thermostat
n/a n/a n/a
Switch #1 Input Status
(0=open,1=closed)
Intelli-Comfort Freeze Thermostat
n/a n/a n/a
Switch #2 Input Status
(0=open,1=closed)
Intelli-Comfort Gas Valve #1 Input
n/a n/a n/a
Status
Intelli-Comfort High Pressure Switch for
n/a n/a n/a
Compressor #1 Input Status (1=closed,
0=open / fault)
Intelli-Comfort High Pressure Switch for
n/a n/a n/a
Compressor #2 Input Status (1=closed,
0=open / fault)
Intelli-Comfort Indoor Fan Output Status
n/a n/a n/a
(0=output is OFF, 1=output is ON)
