Awareness Technology Stat Fax 4200 Operator's Manual page 41

Multi-Point Modes (Point to Point, Regression and Cubic Spline)
(Continued)
The Test Definition first page displays the available options.
Test Definition – 1
If Differential Filter is set to "None", then the Offset Absorbance field is displayed
The Test Definition 2nd page includes use of % Absorbance, number of Standards,
number of Standard replicates, selection of Axes, and the use of Controls.
Note: Point-to-Point and Regression require at least two Standards, Cubic Spline mode
requires at least three.
Stat Fax
TEST DEFINITION
Name
Point to Point
Mode
Primary Filter
Differential Filter
Blank
Offset Absorbance
Print Save
st page with Offset Absorbance field displayed
TEST DEFINITION 2nd page
% Absorbance
Standards
# Std Replicates
Axes Y=Abs X=Conc
Control 1 Disabled
Control 2 Disabled
Control 3 Disabled
<< Save
Test Definition –2nd Page
® 4200 Operator's Manual Doc. 4200 Rev. K
Exit
^
405 v
630
NO Edit
0.000
Run
NO Exit
5
1 ^
v
Edit
Run >>
37
