2.3.4 Utilities

Select Utilities from the Main display screen and Utility Menu options used for diagnostic
purposes will display. The arrow keys control movement up and down the list of options as
well as using the edge of the list to scroll up and down. To select an option from the list,
press the Select button. Press the Done button when finished.
Change Access Level
Show Version Details
Erase ALL Tests
Recall Calibration
Print Unit Settings
Filter Voltages
Check Wheel Speed
The functions of the Utility Menu options are:
Feature
Change Access Level
Show Version Details
Erase All Tests
Recall Calibration
Print Unit Settings
Filter Voltages
Check Wheel Speed
Stat Fax
Utility Menu
Figure 2.3.4-1 Utility Menu options
Display prompts to 'Enter Pass Code'. Contact
Technical Support for pass code.
Displays current firmware version, model, serial
number, build date, current time.
Display will prompt "Please Confirm. Erase All Tests?"
press OK to clear all tests or Cancel.
Allows user to restore the original factory settings,
including calibration.
Prints all information about an individual instrument's
calibration settings and other information.
Displays real time filter wheel voltages; provides
option to print them out. Acceptable range is from 2 to
10 v.
Displays results as the wheel speed is tested.
® 4200 Operator's Manual Doc. 4200 Rev. K
Arrow Keys: Utilize the arrow
^
keys to scroll up and down
the list of options or press the
option directly from the list;
v
the option will be highlighted.
Select: The high-lighted
Select
option is executed once the
Select key is pressed.
Done
Done: Returns to the Main
display screen
Function
21
