2.3.2 Settings

Select the Settings option on the main display screen and the Unit Settings will display:
Adjust Date and Time
Printer Setup
Lamp Control
Plate Assignment
Sound Settings
Laboratory Name
External Output
Plate Print Format
The functions of the Unit Settings features are:
Feature
Adjust Date and Provides access to the Set Time option Hours, Minutes, Seconds
Time as well as Month, Day, Year
Printer Setup Enables/disables the internal printer. Graphs can be printed when
the internal printer is set to OFF. Allows the contrast to be
adjusted light to dark. It is advisable to print at contrast level set at
3. Higher t levels may degrade after several lengthy printouts.
Text height options are small, medium and large.
Lamp Control Lamp idle feature will automatically turn off the lamp; the default
setting is 600 seconds (10 minutes). Lamp Warm up range is
between 45 and 240 seconds (45 seconds is the default setting).
Plate Assignment Offers plate format options such as 8 way or 12 way; duplicates
side by side.
Sound Settings Provides access to and status of touch screen sound settings (ON
or OFF), and sound volume (1=low to 8=high). Sound options are:
start up sound, key press & release and other sounds (i.e. sound
when the Quit button is selected).
Laboratory Name Allows a laboratory named to be entered; laboratory name will
print out (reference Checkout Procedure in Section 1.8).
External Output Allows external output to be turned ON or OFF. Reference the
External Output Section 2.3.2.1 for setup instructions.
Plate Print Format User can select either a 1 to 12 or H to A printout of plate data.
Stat Fax
Unit Settings
Figure 2.3.2-1 Unit Settings
® 4200 Operator's Manual Doc. 4200 Rev. K
Arrow Keys: Utilize the
^
arrow keys to scroll up and
down the list of options or
press the option directly
v
from the list; the option will
highlight
Select
Done
Select: The high-lighted
option is executed once the
Select key is pressed
Function
15
