1.5 Installation
1.5.1 General
Carefully unpack the instrument, removing it from its plastic bag. Report any damage to
your freight carrier at once. Retain the original packing material for future use in the event
that the instrument is shipped to another location or returned for service. Items packed with
the instrument include:
1.5.2 Installation/Preparation
Instrument Placement
and Use
Assure Clean Power
Availability
Power Switch Position
8
Stat Fax
Place the instrument on a flat working surface capable of safely
supporting the weight of the instrument, approximately 5.4 kg (12lbs).
A clearance of at least 8cm (3") around the instrument is required to
assure optimal ventilation.
The circuit used should be substantially free of large voltage
transients (Kilovolt amp loads) such as large pumps, large
centrifuges, refrigerators and freezers, air conditioners, large
autoclaves, ovens, and dryers. The instrument may fail to operate
normally if the power supply is interrupted. If this occurs, turn the
instrument off for a moment. When the instrument is turned back on,
it will resume normal operation, but data that was not stored in
nonvolatile memory will be lost. If power fluctuations or loss are
frequent, an Uninterruptible Power Supply (UPS) is recommended.
The ON/OFF switch is on the back of the instrument. The power
switch should be in the OFF position (down) before connecting the
power cord to the power supply.
®
4200 Operator's Manual Doc. 4200 Rev. K
