Single Standard Mode (Continued)
Selecting the Interpretation Mode field will open the Test Definition Interpretation screen for
editing Interpretation controls. Use the arrow keys to advance through the options, press
the Edit key to change the value of the selection. Press the Done button when editing is
complete.
Single Standard Mode Test Definition - Interpretation

2.5.4 Multi-Point Modes (Point to Point, Regression and Cubic Spline)

The Stat Fax 4200 offers three varieties of multi-point modes: Point-to-Point, Regression
®
and Cubic Spline.
In Point to Point and Cubic Spline modes, the standard concentrations must be read in
either increasing or decreasing order.
All of the Test Definition screens, use of Controls, and items related to Interpretations work
the same for each type of multi-point. Use the arrow keys to scroll through the mode
selections to the desired selection and press Select or use the stylus to highlight
selections.
MULTI-POINT
MODES
36 Stat Fax
TEST DEFINITION Interpretation
Pos/Neg
Interpretation
Pos >=
Neg <
Reversed
Select Mode screen
® 4200 Operator's Manual Doc. 4200 Rev. K
NOTE: Double check
that the interpretation
information entered is
^
correct.
v
NO Edit
Done
