1.5.4 Touch Screen Description

The touch screen responds to touch pressure which causes electrical contact between the
conductive and resistive layers. The touch screen provides the following advantages:
• High touch resolution
• Pressure sensitive, works with any stylus
• Not affected by dirt, dust, water or light
• Durable technology

1.6 Parts and Controls

The following terms are used in this manual to describe parts and controls of the Stat Fax
microplate reader. More details on the operation of each feature are provided in Section 2-
Operating Procedures.
A) Door open
B) Printer and printer
paper compartment
C) Display
A) Power supply module
B) Power switch
C) Power supply connection
D) USB Port
E) USB ports: mouse and thumb drive
F) Stylus
10 Stat Fax
A
Figure 1.6-1 Front of instrument
® 4200 Operator's Manual Doc. 4200 Rev. K
B
Figure 1.6-2 Connections
