2.4.4 Unit of Measurement Codes (Unit Code)

To access the list of Unit Codes, select Manage Tests, select Create Test select any mode
except Absorbance, and advance to the Test Definition Final Page. Select the Units field
and the list will display. Seven units of measurement designations are stored for labeling
the concentration column plus a blank customizable selection.
Create a customized label for the concentration column by selecting the option
'Customize' from the list of units available. A keyboard will display, enter the desired
label name and press Enter. The custom Unit label will display in the Unit field.
26 Stat Fax
TEST DEFINITION Final page
Interpretation Mode Pos/Neg
Units
Decimals
# Sample Replicates
<< Save
Figure 2.4.4-1 Test Definition Final page
Conc
IU/mL
e
g/dL
mmol/L
umol/L
ppm
ppb
Customize
Figure 2.4.4-2 Units of Measure
® 4200 Operator's Manual Doc. 4200 Rev. K
Exit
Conc ^
1 v
1
Edit
Run Print
