Multi-Test - Awareness Technology Stat Fax 4200 Operator's Manual

Feature
Create Test
(Continued)
Edit Test
Delete Test
Multi Test
Clone Test
Print Test List
Exit

2.3.3.1 Multi-Test

With the Multi-Test option, any stored assay regardless of mode or wavelength may
be used. The read direction (8 or 12-way) will be the instrument was set to read in the
Settings menu. With the 8-way format, two, three or six different test modes may be
run in the same plate; with the12-way format up to four tests may be run.
If any test is selected to run in the multi-test plate that has a stored curve, the user
will be prompted to accept, print or discard the curve.
The instrument will prompt the user to select the next test. To read less than a full
plate, select "Cancel" after choosing the last test to be run.
Print Plate will enable the location and absorbance reading of each well to be printed,
as shown on the plate map.
In order to print the test information and results, after each test is run, select
"Results".
If all tests in the multi-test plate have the same filter configuration, then the plate is
read only one time. The user can select "Print Plate" and "Results" for each test.
If different filters are used for any other test(s), the plate will automatically be read
again.
There is no option to select number of wells in Multi-Test.
18 Stat Fax
• Set Blank Minimum and or Maximum
• Set Normal Range Low and or High
• Define Valid Range Low and or High
Used to change test programming. Editing a test will erase any
stored blank or standard values for that test
Allows selection and deletion of user programmed and stored
tests
User can select a number of different tests to be read in the same
plate. (2, 3, or 6 in an 8-way formatted plate or 2 or 4 in a 12-way
formatted plate)
Duplicates an existing test.
Prints the list of stored tests (maximum 120 tests)
Returns to the Main power on display screen
® 4200 Operator's Manual Doc. 4200 Rev. K
Function
