Figure 24
1. Gauge bar
2. Height-adjusting screw
3. Nut
g004552
4. Holes used for setting the
groomer height of groom
(HOG)
5. Hole not used

Product Overview

Controls

Brake Pedals
The 2 foot pedals (Figure
brakes for turning assistance and to aid in obtaining
better side hill traction.
Pedal-Locking Latch
The pedal-locking latch
pedals together to engage the parking brake.
Parking-Brake Pedal
To engage the parking brake,
pedals together with the pedal-locking latch, push
down on the right brake pedal while engaging the toe
pedal. To release the parking brake, press 1 of the
brake pedals until the parking-brake latch retracts.
1. Brake pedal
2. Pedal-locking latch
3. Parking-brake pedal
Traction Pedal
The traction pedal (Figure
reverse operation. Press the top of the pedal to move
forward and the bottom to move backward. Ground
speed depends on how far the pedal is pressed. For
no load, maximum ground speed, fully press the pedal
while the throttle is in the fast position.
To stop, reduce your foot pressure on the traction
pedal and allow it to return to the center position.
Tilt Steering Pedal
To tilt the steering wheel towards you, press the foot
pedal (Figure 25) down, and pull the steering tower
19
25) operate individual wheel
(Figure 25) connects the
(Figure 25) connect the
Figure 25
4. Traction pedal
5. Tilt-steering pedal
25) controls forward and
g015074
