L N PE
230V
KHS isolating valve + spring reset
bn bu
KHS CONTROL-PLUS (Fig. 138 4G)
Pt 1000 (optional) [15] → bu (BU)
bn bu bl gy
K410068602008-00 / 09.2018
[4] → bn (BN) = L
[5] → bu (BU) = N
[7] → ye/gn (YE/GN) = PE
230V +/- 10% AC 50/60Hz
Back-up fuse max. 16A
(Fig. 686 05)
[1] → bn (BN)
[2]
[3] → bu (BU)
[14] → bn (BN)
[17] → bl (BK)
[18]
wh [19] → gy (GY) = Pt 1000 (optional)
[20] → wh (WH) = Pt 1000 (optional)
[21]
If the temperature is measured
using
jumper
changed from 4-wire to 2-wire.
Switch
230V
KHS isolating valve (Fig. 686 04)
bn bl bu
the CONTROL-PLUS,
on the board must
9
[6] → bn (BN) = L
230V +/- 10% AC 50/60Hz
Back-up fuse max. 16A
[1] → bn (BN)
[2] → bl (BK)
[3] → bu (BU)
the
be
