Overview - Kemper KHS Mini Control System MASTER 2.0 Installation And Operating Instructions Manual

In the „OVERVIEW" menu interface, the
configured valves and the linked sensors
are shown in
K410068602008-00 / 09.2018
an

overview.

Pure
measurement valves are not listed in the
"OVERVIEW".
Overview
The overview
current states. No configurations can
be carried out on this interface.
Click a valve to open the input box of
the "SYSTEM
interface of the selected component.
If a valve is highlighted in black, this
means it is closed. If the valve is
highlighted in grey, it is open. If the
valve is highlighted in red, there is a
fault.
Manual mode / Automatic
The actuators
manually. Click the
selection window. Use the selection
window to choose
settings (C valve) or five settings (A/B
valve) from a drop-down list. The
button indicates a fault in the system.
=
Automatic
=
Manual OPEN
=
Manual CLOSE
=
Group OPEN
=
Group CLOSE
After a setting has been selected, the
duration of the setting can be defined.
Use the APPLY
setting. Press the
cancel the action.
60
60
merely shows the
SETTINGS" menu
can be triggered
button to open a
between three
Standard setting
Opens valve
Closes valve
With the A valve, the B
valve also opens
both close again
button to apply the
CANCEL button to
