Main view
When all the devices have been added,
they are displayed in the main view, as

3.1.2.3 Device settings

In the "Device settings" submenu, the
individual Control System are logically
assigned to the integrated actuators
Control type
B valve
A valve
C valve
Safety device
Only
measurement
Configuration of the B Valve
Device selection
When using A/B valve technology, always make sure that the B valve is
configured first. A valves can then be assigned to the B valve. The assignment
of the A valves is shown in the following. For information on valve technology,
please see Chapter 10.1.
K410068602008-00 / 09.2018
Check to see if the antenna icon can always be
seen and if the LEDs light up green on all KHS
Mini Control System. Only then has a proper
connection been established.
Description
Terminal flushing valve, with several A valves hydraulically
preconnected.
Flushing valve which switches the water exchange for one line.
Terminal flushing valve for one line.
Valve which protects a distribution line.
Slave for the acquisition and long-term monitoring of sensor
values.
Valve
See Miscellaneous settings
19
shown below. The individual devices can
then be configured in Device settings.
and sensors. The valve control type is
also determined.
Control type
