Installation
Allow only certified electricians to assemble and install electrical equipment.
Danger of fatal electric shock.
Rigid leads must form a loop for wiring so that there is no pressure on the
terminals and the housing closes without resistance.
Ill. 1 Illustration of the mounting holes for wall installation
Please pay attention to the disturbance space when installing the Control
System.
Left-hand side: Serial number of the KHS Mini Control System
Right-hand side: USB slot
K410068602008-00 / 09.2018
6
Disturbance
space
