3.1.2.2 CAN bus setup

Before device settings can be made, the
Control System or KHS HS2 hygiene
flushing boxes, which are connected to
the -MASTER 2.0- by the CAN bus
cable, must be added to the CAN bus
Adding devices
Term
SL XXXXXX
HS XXXXXX
V1 / V2
V1 / V2
HS XXXXXX
Deactivated
Serial number
Serial number KHS Mini Control System -SLAVE-
Serial number KHS HS2 Hygiene flushing box
K410068602008-00 / 09.2018
Meaning
KHS Mini Control System -SLAVE- including serial number
KHS HS2 hygiene flushing box including serial number
Valve of the KHS HS2 hygiene flushing box (V2 = left; V1 =
right)
No device is added to the selected SLAVE
Ser.Nr.: XXXXXX
S/N: XXXXXX
18
network using the menu item "CAN Bus
Setup". The serial
connected devices are automatically
listed, and are assigned to a SLAVE in
the system.
Even if the KHS HS2
has two valves, it
only has one serial
number.
numbers of
