Configuration of the safety device
Configuration of measurement (datalogging)
K410068602008-00 / 09.2018
Select type
After a line has been added using
LINE, the line type is selected. The
"Release" line type is selected from the
drop-down list.
Define time
After a line type has been selected,
define the times. A starting and stopping
time has to be specified for the "Release"
line type. Furthermore,
weekdays can be selected from a drop-
down list. Click in the box of the weekday
in question to activate it with a check
mark.
Select type
Na er a line has been added using
LINE, the line type is selected. The KHS
Mini Control System in this sample
project is connected to a KHS Control
Plus flow measurement valve. To record
the flow
measurement data at the same time, the
"Datalogging" line type must be selected
from a drop-down list.
58
ADD
the desired
ADD
measurement valve
