Installing and adjusting Pressure Lever cassettes
1. Switch the pump off
2. Push the pressure lever down (it must be relaxed)
3. Insert the tubing with color‐coded collars into cassette
4. Reinsert the cassette(s) onto the rollers. Ensure that it snaps in on both sides
5. Switch the pump on and start it
6. Lift the pressure lever step by step until the medium is drawn in and a continuous flow is achieved
Notes on Pressure Lever Cassettes
– Under certain circumstances (e.g. new tubing, elevated differential pressure, etc.) we recommend the user
lift the lever by just one more step
– Never over‐tighten the pressure lever
– The setting of the pressure lever determines the occlusion
– The optimum occlusion depends on tubing material, inner diameter, wall thickness, age of tubing, and
application conditions
– As a side‐effect, the occlusion setting also affects the flow rate
‐ This, however, should not encourage the user to use the pressure lever for flow rate adjustments because
long‐term impact is not predictable
– If, however, the occlusion setting is used to adjust the flow rate, the channel‐to‐channel flow rate
conformity may lead to good results in the beginning of the operation, yet the individual flow rates may
increasingly diverge at a later stage
– For an optimum long‐term flow rate stability and channel‐to‐channel conformity we suggest using the Click‐
n‐Go© cassettes.
9

Repair

The Reglo ICC is designed for many years of trouble free service. The Reglo ICC does not have any fuses or
adjustments inside the pump. If you wish to attempt any repairs after the warranty period, please contact your
local Ismatec Distributor for parts.
10 Cleaning
When replacing the tubes and/or cassettes the pump head should be wiped to avoid any debris or residue. The
pump head can be cleaned with mild detergent water before and after duty cycles for extended life. The exterior
of the pump can be gently wiped with IPA (Isopropyl Alcohol). Use a 50% mixture of IPA and water on a lint‐free
soft cloth to clean the LCD screen. Do not spray or pour any liquid on the LCD screen.
11 Disposal
Please retain packing materials until the product warranty ends. Afterwards please discard packing materials in an
environmental friendly manner according to local regulations. Once the useful life of the product has ended,
please ensure proper disposal according to local laws. Plastic and electronic components should be disposed of at
a recycling facility. Please refer to local regulations regarding proper disposal.
