14 IDEX Reglo ICC Serial Command Protocol
The Reglo ICC Pump supports a serial communication protocol for controlling the pump's operation as
well as setting and getting current pump configuration parameters.
Each pump has a configurable address (1‐8) which is set to 1 at the factory. This address is used with all
direct‐addressed commands to send the command to single pump on a multi‐pump serial daisy‐chain of
pumps. The set address command is used to reconfigure a pump's address, but is received by every
pump in the chain.
All protocol messages are composed of ASCII characters.
ASCII Character Definitions
The following symbols are used in the message definitions in this document.
•
[SP] – space (0x20)
•
[CR] – carriage return (0x0d)
•
[LF] – line feed (0x0a)
Definitions
•
* – default command response message.
Set Address Command
Direction: PC‐to‐pump
This is a specially formatted command used to set the address of each pump. By default, each pump
uses address 1.
@
Char Width
1
•
@ ‐ The "@" character (ASCII 0x40).
•
Addr – The new pump address (1 – 8).
•
[CR] – A carriage return character.
The response to this command is a default command response message.
Default Command Response (*)
Direction: Pump‐to‐PC
A pump status response message is the default response of the pump to most commands, indicating a
success or failure of the command. This message may be sent in response to the set address command
or direct‐addressed commands.
Addr [CR]
1 1
