Ismatec Reglo ICC Operating Manual page 16

Status
Char Width 1
•
Status: A single ASCII character indicating the execution status of the requested command.
o * (0x2a) ‐ The command was executed successfully.
o # (0x23) ‐ The command was not executed successfully.
o – (0x2d) ‐ A negative response used for some commands, with different meanings for
each. See individual direct‐addressed command definitions for context.
o + (0x2b) ‐ A positive response used for some commands, with different meanings for
each. See individual direct‐addressed command definitions for context.
Direct­Addressed Command
Direction: PC‐to‐pump
A direct‐addressed command is addressed to an individual pump to get or set particular pump
parameters. Each of these commands is described in the Direct‐Addressed Command List below.
Addr
Char Width
1
•
Addr : The address of a pump to send a command to (1 – 8).
•
Command: Individual commands, with an optional argument, as defined in the Direct‐Addressed
Command List below.
•
CR: A carriage return character (ASCII 13).
Direct‐Addressed Command List
Ref Command Argument
#
General Information
1
‐
Drive Control
2 H
3 I
4 J
5 K
6 A
7 B
Command CR
1
Variable
Function
Reset an overload condition.
Start pump.
Stop pump.
Set rotation direction to clockwise.
Set rotation direction to counter‐
clockwise.
Unset the pump as "under external
control." The pump may now be
controlled locally. Enable the pump
display and keypad entry.
Set the pump as "under external control." Set
Op Response
Set *
Set *
‐
The pump is in Volume
(over time) mode and the
current settings are not
achievable.
Set *
Set *
Set *
Set *
*
