Ismatec Reglo ICC Operating Manual page 19

Ref Command Argument
#
41 %
42 (4)
‐‐‐‐
%
43 T
44 (4)
‐‐‐‐
T
45 (3)
‐‐‐
TM
46 (3)
‐‐‐
TH
47 "
48 (4)
‐‐‐‐
"
49 :
50 W
51 *
52 0
Inputs and Outputs
53 C
Examples
Set speed of pump 1 to 098.76 RPM
Command
1S009876[CR]
Response *
Set speed of pump 1 to 98 RPM
Command 1S009800[CR]
or
Command
1S0098[CR]
Response *
Function
Get the current backsteps setting.
Set the current backsteps setting.
Get the current setting for pause time in
1/10 second.
Set the current setting for pause time in
1/10 second. Format Is HTU.t
Set the current setting for pause time in
minutes (0 – 999). Format is HTU.
Set the current setting for pause time in
hours (0 – 999). Format is HTU.
Get the current setting for pump cycles.
Set the current setting for pump cycles.
Format is THUT.
Get the total (trip) volume pumped since
the last reset in ul, ml or liters.
Reset the total (trip) volume count.
Force the pump to save its current pump
settings values ( time, pause time, speed,
backsteps, cycle count, etc) to non‐
volatile memory. They will be available
after device power down.
Sets all the current pump setting values
above to "default" and saves the settings.
Get the current state of the foot switch.
Op Response
Get 0[CR][LF]
Set *
Get 105[CR][LF]
Set *
Set *
Set *
Get 0[CR][LF]
Set *
Get 4.983[SP]ml[CR][LF]
Set *
Set *
Set *
Get ‐ open
+ grounded
