Ismatec Reglo ICC Operating Manual page 17

Ref Command Argument
#
8 (5) Numeric
‐‐‐‐‐
D
digits to write
to the control
panel.
9 (4) Alphabetic
‐‐‐‐
DA
characters to
write to the
control panel.
10 L
11 M
12 N
13 O
14 ]
15 P
16 Q
17 G
Parameter Control
18 E
19 #
20 (
21 )
Function
The pump display is under the control of
the D and DA commands and keypad
entry at the pump is disabled.
Write numbers to the pump to display
while under external control.
Write letters to the pump to display while
under external control.
Set pump to RPM mode.
Set pump to Flow Rate mode.
Set pump to Time mode.
Set pump to Volume (at rate) mode.
Set pump to "pause" mode. This
essentially stops the pump.
Set pump to Time + Pause mode.
Set pump to Volume + Pause mode.
Set pump to Volume (over time) mode.
Returns whether the pump is currently
running or not.
Returns the following fields, each
separated by a space:
Pump model description (variable
length)– A text field describing the model
of pump. This description may contain
spaces.
Pump software version (3 digits) – The
version of software currently running in
the pump.
Pump head model type code (3 digits) –
A code describing the type of pump head
installed. The first digit represents the
number of channels for the pump, and
the second 2 digits represent the number
of rollers.
Returns the pump software version –
The version of software currently running
in the pump. This value is returned in 4
characters with the value right justified
and zero‐padded.
Returns the pump head model type code
– A 3 digit code describing the type of
pump head installed. The first digit
represents the number of channels for
Op Response
Set *
Set *
Set *
Set *
Set *
Set *
Set *
Set *
Set *
Set *
‐
volume too small and
time too long
+
volume too large and
time too short
Get
+
running
‐
stopped
Get [model][SP][s/w
ver][SP][head
code][CR][LF]
Get 0123[CR][LF]
Get 0123[CR][LF]
17
