Ismatec Reglo ICC Operating Manual page 18

Ref Command Argument
#
22
‐‐‐‐
)
23 S
24 (4‐6) speed
‐‐‐‐ ‐‐
S ( )
25 +
26 (4) tubing
‐‐‐‐
+
diameter
27 V
28 (4) time
‐‐‐‐
V
setting
29 (3) time
‐‐‐
VM
setting
30 (3) time
‐‐‐
VH
setting
31 U
32 (5) roller steps
‐‐‐‐‐
U
33 (4‐5) high‐
‐‐‐‐ ‐
u ( )
order roller
steps
34 r
35 (6) roller step
‐‐‐‐‐‐
r
volume
36 r000000
37 f
38 (6) flow rate
‐‐‐‐‐‐
f
39 v
40 v (6) volume
Function
the pump, and the second 2 digits
represent the number of rollers. This
value is returned in 4 characters with the
value right justified and zero‐padded.
Sets the pump head model type code – A
3 digit code describing the type of pump
head installed. The first digit represents
the number of channels for the pump,
and the second 2 digits represent the
number of rollers. This value must be set
with 4 characters with the value right
justified and zero‐padded.
Gets the current speed setting in RPM
with 2 decimal places.
For 4, 5,or 6 digits, the units are 1/100
RPM. Format is 0HTU.th.
Get the current tubing inside diameter in
mm. 2 decimal places are returned.
Set the current tubing inside diameter in
1/100 Format is TU.th
Get the current setting for pump time in
1/10 second.
Set the current setting for pump time in
1/10 second. Format is HTU.t
Set the current setting for pump time in
minutes (0 – 999). Format is 0HTU.
Set the current setting for pump time in
hours (0 – 999). Format is 0HTU.
Get the current setting for volume to
pump in roller steps.
Set the current setting for volume to
pump in roller steps (0 – 65535).
Use to set the current setting for volume
to pump in roller steps to a value greater
than 65535. When set, the number of
steps to pump is (u * 65536) + U.
Get the pump's current setting for roller
step volume (RSV) in nanoliters (nl).
Set the pump's current setting for roller
step volume (RSV) in nanoliters (nl).
Format is xxxxee
Set the pump's current setting for roller
step volume to the default value. This
sets RSV to the value indicated by the
pump's internal table based on pump
heads and tubing sizes.
Get the current setting for flow rate in
ml/min.
Set the current setting for flow rate in
ml/min. Format is U.thtee.
Get the current setting for volume in ml.
Set the current setting for volume in ml.
Format is U.thtee
Op Response
Set *
Get 100.00[CR][LF]
Set *
Get 1.23[SP]mm[CR][LF]
Set *
Get 105[CR][LF]
Set *
Set *
Set *
Get 100[CR][LF]
Set *
Set *
Get 9500E‐1[CR][LF]
Set *
Set *
Get 1200E‐2[CR][LF]
Set 1200E‐2[CR][LF]
Get 6320E+1[CR][LF]
Set 6320E+1[CR][LF]
18
