1.2 Mechanical specifications

Model SC-800 Propane
Grinding diameter 32" / 800 mm
Grinding plate diameter 9.5" / 240 mm
Grinding plate speed 550 – 960 RPM
Mass
970 lbs / 440kg
Gear barrel Synchronized
Table 1-2
Mechanical specifications
Measurements of SC-800 Propane
Width 820 mm (32.3")
Height 1500mm (59")
Depth 1120 mm (44.1")
Ambient temperature range during operation
Ambient temperature range during storage
When using water the ambient temperature must never fall below 0°C (32°F).

1.2.1 Water connection

Inside the cover of the gear barrel there is a sprinkler system connected to an external water
connection. The water connection comes with its counterpart and fits a standard ½ inch hose. At
the connection that is fitted near the handle there is a tap to adjust the flow.
- 44 -
44
-10°C to +50°C (14°F to 122°F)
-40°C to +70°C (-40°F to 158°F)
