4 Operation

4.1 Preparation

Before first start-up make sure that the oil level is correct by checking the oil gauge filler.
Choose engine oil that follows API Service Classification: SF, SG, SH, SJ or SL.
Choose viscosity according to temperature were the machine will be operated.

4.2 Precautions

Any machine, if it is not used according the regulations, may be hazardous for operating,
setting-up and service personnel. The operating authority is responsible for compliance with
the safety regulations during operation and maintenance, and for the use of safety devices
supplied with the machine, as well as the provision of appropriate additional safety devices!
All propane connections and cables must be inspected for potential damages.
Never operate the machine without proper tools.
Eye and ear protection must be worn at all times.
Never operate the machine when it's not in its upright position.
Make sure there is no debris in the work area.
Check the work area for screws or other hard objects in the concrete. Don't use the machine
if there are any foreign objects stuck into the surface. Such objects must be removed prior to

operation of machine.

Read "2Safety Regulations" before operating the machine.
4.3 Operation of machine
The gear barrel has got three grinding heads that rotates in the opposite direction of the gear barrel.
Each grinding head is equipped with a Scan-on plate where each plate hold the tools used. See
"Figure 4-1".
- 62 -
62
SCAN COMBIFLEX 800 PROPANE
www.scanmaskin.com www.scanmaskin.com
Scan Combiflex 800 Propane - Manual
Figure 4-1 Illustrates the rotation of the grinding heads versus the gear barrel.

4.4 Using the handle

Figure 4-2 Secure the handle
Figure 4-4
Figure 4- 3 Handle upraised Handle in working position
- 63 -
ENGLISH
Figure 4-4 Handle lowered
