Job Aid: S8300 Communication Manager and co-resident SES: Replacing the S8300C or S8300D Server or

Install the replacement hard drive or server

Note:

If you are replacing both the server and the hard drive, complete Steps

Note:

then skip to Step

To install a new hard drive and/or replace the S8300C or S8300D Server:

1. Loosen the two thumb screws on the S8300C or S8300D Server.

2. Remove the S8300C or S8300D Server from the media gateway.

3. From the bottom of the S8300C or S8300D Server, remove the two screws that attach to the

hard-drive standoffs (Refer to

24 Job Aids for Field Replacements (FRUs) for the Avaya S8300 Server with the G700 Media Gateway

and complete the remainder of this section.

Figure 3: S8300C hard drive replacement

and 2,

on page 25).
