2. GENERAL

2.1. General view

Legend:
1:1 Lateral polyester doors (hinged)
1:2 Safety photocell
1:3 Lateral extension doors (removable)
1:4 Hoods
1:5 Fixed obstacle
1:6 Mobile obstacles
1:7 Ticket reader (option)
1:8 Detection photocells (behind smoked plexiglass strip)
1:9 Orientation pictogram (option)
Note: Conventionally and as a general rule, the user will be considered in direction "A" when the gate is at his
right side, in direction "B" when the gate is at his left side. Direction A is typically the entry direction into
the paid area, while direction B is the exit.
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
1:5
1:8
1:1
1:4
PNG380
1:3
1:1
1:2
PNG382
10/12/01
1:6
1:6
1:3
1:8
PNG381
1:4
1:3 1:9
All intermediate type PNG elements
1:4
1:7
p. 5/51
