Variables:
Only the internal variables included below may be modified with the FTX117 console.
Variable
Lc_mem_lc
%M3
Detect_p_t
%M9
Sel_pass
%M34
A3
Mode_sens_contraire
%M36
A3
%M46 Ext_cel_a
%M47 Ext_cel_b
%M85 Mode_sortie_libre
A3
%M113 Act_evacuation
%MW0 Phase_png
%MW1 Cfg_pic_a
%MW2 Nb_lc_a
Nb_lc_b
%MW3
%MW4 Cfg_safe
Cfg_pic_b
%MW8
Cel_state
%MW12
%MW21 Min_cel_zone_a
A3
%MW22 Min_cel_zone_b
A3
Nb_cel_pass
%MW29
A3
%MW30 Max_cel_zone
A3
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
Name
Counting the number of passage authorizations:
0: no counting
1: counting
Tailgating fraud detection before passage through doors (DIP3 of word3):
0 : No tailgating detection before passage through doors
1 : Tailgating detection before passage through doors
Type of passage contact :
0: Passage contact when the person has left the entry zone
1: Passage contact when the person has completely left the PNG
Detection of opposite direction fraud (DIP2 of word3):
0 : Detection of opposite direction entrance over 3 cells
1 : Detection of opposite direction entrance over 2 cells
Cell extension – direction A:
0: absent (PNG380)
1: present (PNG381-PNG382)
Cell extension –direction B:
0: absent (PNG380-PNG381)
1: present (PNG382)
Type of detection of opposite direction fraud in "Free exit" mode (DIP6 of word3):
0 : Reinforced detection
1 : Reduced detection
Activation level of the evacuation mode (DIP5 of word3):
0 : Evacuation if connection 5-6 of X13 is open
1 : Evacuation if connection 5-6 of X13 is closed
Program stage.
Configuration of pictograms in direction A:
0: limited management
1: extended management
Number of passage authorisations in direction A
Number of passage authorisations in direction B
Configuration of safety system:
Bit 1
Bit 2
Bit 3
Bit 4
Configuration of pictograms in direction B:
0: limited management
1: extended management
State of the cells:
X15 indicates the state of the cell C1; X14 of C2; X13 of C3... X1 of CS; X0: 0
Detection of the number of zones: number of cells per zone in direction A
Default value 2.
Detection of the number of zones: number of cells per zone in direction B
default value: 2.
Number of free cells for detection of passage through doors.
Maximum number of cells in an entrance zone before starting a zone fraud.
0: C6 excluded from the group
1: C6 included in the group
0: C7 excluded from the group
1: C7 included in the group
0: C13 excluded from the group
1: C13 included in the group
0: C14 excluded from the group
1: C14 included in the group
