4.7. Visualization and description of entries on the PLC

FTX117 or
programme
reference
Q4.0
Q4.1
Q4.2
Q4.3
Q4.4
Q4.5
Q4.6
Q4.7
Q4.8
Q4.9
Q4.10
Q4.11
Q4.12
Q4.13
Q4.14
Q4.15
Q4.16
Q4.17
Q4.18
Q4.19
Q4.20
Q4.21
Q4.22
Q4.23
Q4.24
Q4.25
Q4.26
Q4.27
Q4.28
Q4.29
Q4.30
Q4.31
Note: In order to display the inputs from Q16.0 to Q16.15 thanks to the PLC LEDs, press the « DIAG »
button for less than one second until the digit 16 appears.
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
PLC LED
0 NO mode display
1 NF mode display
2 Controlled – Direction A display
3 Free – Direction A display
4 Locked – Direction A display
5 Controlled – Direction B display
6 Free – Direction B display
7 Locked – Direction B display
8 Pulse contact – Direction A
9 Passage contact – Direction B
10 Display – Technical alarm
11 Display – Fraud
12 VSC – Opening command
13 VSC – Opening limit switch
14 VSC – Closing limit switch
15 Reserve 1
16.0 Cross orientation pictogram – Direction A
16.1 Arrow orientation pictogram – Direction A
16.2 Arrow operation pictogram – Direction A
16.3 Cross operation pictogram – Direction A
16.4 Card orientation pictogram – Direction A
16.5 LCD pictogram – Strobe
16.6 Cross orientation pictogram – Direction B
16.7 Arrow orientation pictogram – Direction B
16.8 Arrow operation pictogram – Direction B
16.9 Cross operation pictogram – Direction B
16.10 Card orientation pictogram – Direction B
16.11 Card reader – Passage contact– Direction A
16.12 Card reader – Reader locking – Direction A
16.13 Card reader – Passage contact – Direction B
16.14 Card reader – Reader locking – Direction B
16.15 Reserve 2
