4.4. Time-outs, pulses and variables

All the values of the time-outs, periods and variables of the PNG programme stated below can be modified with
the FTX117 ADJ02 console which is connected to the PLC. The table below shows also the default values.
Time-outs:
It is necessary to multiply the time-out value by the time base in order to obtain the duration in seconds.
Time-out
%TM0
%TM1
%TM2
%TM3
%TM4
%TM5
%TM6
%TM7
%TM9
%TM10
%TM11
%TM12
%TM13
A3
Period of contact:
Pulse
%MN0
%MN1
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
Name Time base Default value
T_intrusion 100ms
T_free_open 100ms
T_pre-alarme 100ms
T_no_pass 100ms
T_ferme_porte 100ms
T_contraire 100ms
T_train 100ms
T_fin_pass 100ms
T_t_o_pass 100ms
T_safe_open 100ms
T_safe_close 100ms
T_full_free 100ms
T_wait_open 100ms
Name Time base Default value
M_new_lc_a 100ms
M_new_lc_b 100ms
10 Maintains the alarm when the "intrusion" fraud cancels.
20 Duration while the obstacle remains open after the user
has left the entry zone in the "free in one direction"
mode.
150 Time limit before activating the buzzer on intrusion.
150 Time limit before returning to stand-by mode if no
passage after an authorisation.
5 Duration while the obstacle remains open after the user
has left the entry zone in the "free in one direction"
mode.
10 Maintains the alarm active when "opposite direction"
fraud cancels.
10 Maintains the alarm active when "tailgating" fraud
cancels.
10 Time limit to return to the stand-by mode after a
controlled passage.
100 Maximum time limit allowed to end the passage in
progress after the obstacle closing.
40 During an
corresponding limit switch is not reached by the end of
this time-out, the obstacle reopens.
20 Duration while the obstacle remains open on a safety
closure (T_safe_open).
30 Duration while the obstacle remains open after the end
of the passage in the PNG in "free in both directions"
mode.
3 Time limit before opening the doors after cancellation of
safety
7 Passage pulse duration in direction A.
7 Passage pulse duration in direction B.
10/12/01
Description
obstacle closing sequence,
Description
p. 31/51
if the
