8. MECHANICAL ADJUSTMENTS AND INTERVENTIONS

WARNING!
REMINDER: Y
OUR AUTOMATIC GATE TYPE
. A
COMPONENTS NY NEGLIGENCE DURING AN INTERVENTION IN THE MACHINE MAY SERIOUSLY ENDANGER YOUR SAFETY
SOON AS YOU OPEN THE HOUSING
WHICH IS LOCATED BEHIND THE LATERAL POLYESTER DOOR
MIGHT BE UNDER POWER OR COULD BE SET IN MOTION

8.1. Limit switch cam adjustment

•
The obstacle is closed in the "0 position" if the points (x), (y), and (z) of the crankshaft-rod device are
perfectly aligned as illustrated in Fig. 24. If the factory-set alignment of these points is correct, the obstacle in
open position (i.e., with passage-way closed) must be locked, with a minimum play, and with motor stopped.
To correct the limit switch cam, proceed as follows:
x
z
y
Passage-way closed
-- Ensure that the equipment is powered off (main magneto-thermal circuit breaker disengaged).
-- Manually set the geared motor crank (24:1) to a distance of 40 mm from the closing abutment (lower
rubber bumper).
-- Loosen the two locking screws of the cam (24:2), and slightly move the cam in either direction until the
limit switch is engaged (a click sound can then be heard).
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
"PNG380/381/382"
,
SWITCH OFF THE MAIN MAGNETO
(10:1). B
.
0.1mm
24:2
10/12/01
COMPRISES A MECHANISM AND VARIOUS ELECTRICAL
-
THERMAL CIRCUIT BREAKER
E CAREFUL IN HANDLING ANY INTERNAL ELEMENT WHICH
24:3
24:1
Legend:
24:1 Geared motor crank
24:2 Limit switch cam
24:3 Opening limit switch (FCO)
24:4 Rubber bumpers
. A
S
(2:1) ,
OF THE MASTER GATE
24:4
p. 47/51
