4.3. PNG configuration

Three "configuration words" determine the operation mode of the PNG series 380. The PNG is configured by
positioning the SW3 (2:7) DIP switches on the AS1007 interface board on ON (1) or OFF (0). Press the push
buttons as indicated in the procedure below in order to validate a configuration word.
After the initial configuration, the parameters can be modified by means of the programming console FTX117
ADJ02 to be connected on the plug (2:9) of the PLC.
Note: the DIP values in bold correspond to the factory configuration
Warning: Do not press the DIAG button!
If you press on DIAG for more than 5 seconds after switch-on or resetting, you will erase the
programme and the PNG cannot be operated
1. Switch off the PNG main power supply.
2. Switch off the variable speed controller power supply.
3. Disconnect the connector X15.low (Desk), the connectors X13.low (LC.A.) and X13.up (LC.B.).
4. Switch on the main power supply.
5. Press RESET (the button (2:8) is located on the PLC fascia).
6. Set the DIP switches according to the tables below in order to configure
6.a. PNG type
DIP 1
0
0
1
1
6.b. Management of pictograms direction A (See Chapter 4.2.3.)
DIP 4
0
1
6.c. Management of pictograms direction B (See Chapter 4.2.3.)
DIP 6
0
1
6.d. DIP 3 and DIP 5 always at 0
7. Press the L.C.A. push-button (2:11), wait for the validation signal and release the button.
8. Set the DIP switches according to the tables below in order to configure
8.a. DIP 1 always at 0
A3
 Automatic Systems PNG38X-A3_1-04-gb-02.doc
Procedure
DIP 2 Configuration
0 PNG380
1 PNG381A
0 PNG381B
1 PNG382
Configuration
Limited management
Extended management
Configuration
Limited management
Extended management
10/12/01
word 1
.
word 2.
